      1756-CNBR

      ControlLogix communication module

      Product Information

      Product Describe

      ControlLogix communication module. This

      module is a ControlNet Bridge communication

      module that features Two (2) ControlNet

      ports supporting simplex and redundant

      ControlNet network


      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC System
      • Spare Part Number:
        1756CNBR
      • Estimated shipping dimensions:
        17x13x3.2cm
      • Weight:
        0.25 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • No. of Ports:
        Two (2) ControlNet ports
      • Isolation Voltage:
        30 Volts Continuous
      • Power Dissipation (Max):
        5.5 Watts
      • Enclosure:
        Open Type
      • Operating Temperature:
        32-140 Fahrenheit (0-60 Celsius)
      • ControlNet Rate of Communication:
        5 Mbps
      • Current Draw at 5.1 Volts DC:
        970 Miliamperes
      • Product Line:
        ControlLogix
      • Stock:
        30
      By purchasing this item, you agree to the Terms & Conditions
      Moore Automated is NOT an authorized distributor of Allen-Bradley
      right background
      1-year warranty

      All our products come with a 1-year warranty for your peace of mind.

      Service means taking a customer problem and making it your own challenge. Years of experience and listening skills enable us to think and act quickly and accordingly. You have a problem? – We have the solution!
      Moore Automated is not an authorized distributor, reseller or representative of the products featured on this website.
      All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
      Learn More Policy
      Manuals
      • Order Online:
        We have been working hard to update our inventory.

        If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show “Ask”. Please create an online quote or contact us by phone, fax or email to check availability.
      • Order by:
        You can also contact us by phone, fax or email to order. We are here to help you!
      • E-mail:
        We need the following information to process your order quickly and accurately: Your complete ship and receipt information
      • Delivery:
        How do you want to ship? Shipping information
      • Payment:
        How will you pay? Payment procedure
      Learn More Policy
      Quantity*
      Mobile*
      Company
      E-mail*
      Content*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote

      Quick Search

      • Part or Model Number

        • Please try to be as accurate as possible with your search.
        • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
        • We can't find any results for “”.
          SEE MORE
            SEE PRODUCTS IN SEARCH PAGE ()

          • Filter by Manufacturer

          • Filter by Category

          Featured Manufacturers

          FAQ

          • What primary communication role does the 1756-CNBR serve within a ControlLogix architecture?
            The 1756-CNBR is a ControlNet redundant bridge module that facilitates deterministic data exchange between a ControlLogix controller backplane and the ControlNet network, enabling both scheduled and unscheduled messaging for real-time industrial automation.
          • How does the 1756-CNBR implement redundancy to enhance network fault tolerance?
            The 1756-CNBR supports two independent ControlNet BNC ports (A and B), allowing dual-media ControlNet trunk connections. This redundant media capability helps maintain network communication continuity if one physical path is interrupted.
          • How many communication connections can the 1756-CNBR maintain for Logix devices and other nodes?
            This module can support 40 to 48 Logix communication connections, and up to 64 total bidirectional connections, accommodating a large number of peers in complex industrial networks. It also supports up to 99 ControlNet nodes on the network.
          • What physical cabling and connector types are used by the 1756-CNBR for ControlNet media?
            The 1756-CNBR uses quad-shielded RG-6 coaxial cable terminated via BNC connectors for the redundant media paths, which is required for reliable ControlNet signal integrity over long distances.
          • What are the electrical and backplane power specifications of the 1756-CNBR?
            The module draws approximately 970 mA at 5.1 VDC from the ControlLogix backplane and 1.7 mA at 24 VDC, with a typical power dissipation of ~5.1 W and corresponding thermal load.
          • How does the module’s isolation rating contribute to electrical protection in a control system?
            The 1756-CNBR provides 30 V continuous basic insulation between the ControlNet media connections and the backplane, enhancing electrical safety and reducing susceptibility to ground loops or network-induced noise.
          • Is the 1756-CNBR still current, and what is the replacement strategy for future deployments?
            The 1756-CNBR is officially discontinued as of December 31, 2024. Customers are advised to plan migrations to newer modules such as the 1756-CN2R series, which provides similar redundant ControlNet communications with updated platform support.
