      In Stock
      IGBT module

      BGAD-22C 3AXD50000007344

      Spare Part Number

      PNFS300R12OE4

      Product Information:

      IGBT MODULE 1200V/300A

      1200 V, 300 A sixpack IGBT module

      EconoPACK+Modul mit Trench/Feldstopp

      IGBT 4und Emitter Controlled HE

      Diodeund PressFIT/NTC

      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs
      Technical specifications for

      BGAD-22C 3AXD50000007344

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        ABB
      • Product Category:
        Inverter Drives
      • Spare Part Number:
        FS300R12OE4
      • Estimated shipping dimensions:
        11 x 25 x 5.6 cm
      • Weight:
        0.33 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        sweden
      • Place of shipment:
        Xiamen, Fujian, China
      • Product Type:
        IGBT-modules
      • Isolation test voltage:
        RMS, f = 50 Hz, t = 1 min
      • Temperature:
        150°C
      • Voltage and Frequency:
        1200V/300A
      • Series:
        ABB Drives
      • Stock Availability:
        20
      Ask for Quote
