1786-RPA

ControlNet Modular Repeater Adapter
In Stock

Product Information:

ControlNet Modular Repeater Adapter

This module is used to extend the length

of the ControlNet network. Tit has One

(1) Coax cable port, powered by a 24VDC

power supply

Expand All
Collapse all

Technical specifications for 1786-RPA

  • Manufacturer:
    Allen-Bradley
  • Product Category:
    PLC System
  • Spare Part Number:
    1786RPA
  • Estimated shipping dimensions:
    10x9.9x7cm
  • Weight:
    0.2 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
  • No. of Coax Channel:
    One (1)
  • Product Family:
    ControlNet communication
  • Mounting:
    Panel Mount / DIN Rail
  • Mounting orientation:
    Vertical / Horizontal
  • Power Supply, nominal:
    24VDC
  • Power Supply, range:
    18-36VDC
  • Power Consumption, max:
    16.8 W
  • Stock:
    20

Manuals

Ask our team:

  • What are the electrical and physical interface specifications of the 1786-RPA that facilitate seamless integration into ControlNet topologies?
    The 1786-RPA module interfaces with standard ControlNet coaxial cables and adheres to the ControlNet physical layer specifications, providing two independent ports for daisy-chaining network segments while maintaining robust isolation and impedance matching for optimal network performance.
  • In what scenarios is deploying the 1786-RPA particularly advantageous for ControlNet network architecture?
    The 1786-RPA is indispensable in large-scale industrial installations requiring network expansion beyond the 1000-meter coaxial cable limit, enabling network designers to segment ControlNet communication paths, reduce signal reflections, and improve overall system reliability.
  • What diagnostic features are incorporated in the 1786-RPA to facilitate proactive network maintenance and fault isolation?
    The 1786-RPA provides LED status indicators for power, network health, and communication activity, allowing operators to rapidly identify signal faults, power anomalies, or network connectivity issues, thus enabling timely troubleshooting and minimizing unplanned downtime.
  • Can the 1786-RPA be used in redundant ControlNet network configurations to enhance system availability?
    Yes, the 1786-RPA supports redundant network architectures by allowing duplicated ControlNet segments to be seamlessly bridged, thereby enhancing network fault tolerance and ensuring continuous system operation in critical industrial environments.
  • How does the 1786-RPA facilitate network scalability while maintaining adherence to ControlNet protocol constraints?
    By strategically inserting the 1786-RPA modules within the network, engineers can extend ControlNet segments beyond the inherent physical limitations, enabling scalable system growth without violating timing or network load parameters prescribed by the ControlNet specification.
