      Allen-Bradley 1756-L81E
      Allen-Bradley 1756-L81E
      Allen-Bradley 1756-L81E
      Allen-Bradley 1756-L81E
      Allen-Bradley 1756-L81E
      Allen-Bradley 1756-L81E
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote

      1756-L81E

      Controller CPU Module
      In Stock
      Ships by Tuesday, June 23
      Fast Shipping Available

      Product Information:

      The Allen-Bradley 1756-L81E is a high-performance ControlLogix 5580 programmable automation controller (PAC) manufactured by Rockwell Automation. It represents the entry-level memory capacity of the L8x (5580) flagship platform, offering faster processing speeds, integrated motion control functions, and high-speed communication capabilities compared to the traditional L7x series.

      The Allen-Bradley 1756-L81E features rich task management capabilities. This model can efficiently handle up to 32 tasks, enabling high flexibility and complex operations.

      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 1756-L81E

      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC System
      • Estimated shipping dimensions:
        20.3 x 15.6 x 14.5 cm
      • Weight:
        1.23 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Isolation Voltage:
        50 Volts Continuous
      • Power Dissipation:
        6.2 Watts
      • Current Draw (5.1 Volts):
        1.20 Miliamperes
      • Current Draw (1.2 Volts DC):
        5.0 Miliamperes
      • User Memory:
        3 MB
      • I-O Memory:
        N/A
      • Product Line:
        ControlLogix
      • Product Type:
        Controller module
      • Number of Tasks:
        32 Tasks
      • Number of Programs per Task:
        1000 Programs per Task
      • USB Ports:
        1 Port
      • USB Port Speed:
        12 Mbps
      • Ethernet Port:
        1 Port
      • Ethernet Port Speeds:
        10, 100, or 1000 Mbps
      • Supported Communication:
        Ethernet,ControlNet,DeviceNet,Remote I/O
      • Stock:
        100
      Ask for Quote

      Revisions

      Revision Part #

      Also known as

      1756-L81E/A
      1756-L81E Ser A, Series A, Rev A
      Get Parts Quote
      1756-L81E/B
      1756-L81E Ser B, Series B, Rev B
      Get Parts Quote

      Alternative Names

      1756L81E 1756 L81E I756-L8IE 1756-LB1E I756L81IE 1756LB1E 1756-L82E 1756-L83E 1756-L85E 1756-L84E 1756-L81E-NSE 1756-L81E-NSEXT 1756-L81EXT 1756-L81EK 1756-L81EP 1756-L81EPXT 1756-L81ES

      Information

      Overview Manuals Principle Core Applications

      Features:

      • Standard ControlLogix Series Industrial Controller
      • It is equipped with a USB port and an embedded Ethernet port
      • The 1756-L81E standard controller supports Ethernet communication speeds of 10 Mbps, 100 Mbps, and 1000 Mbps
      The Allen-Bradley 1756-L81E standard controller communicates via Ethernet at speeds of 10 Mbps, 100 Mbps, and 1000 Mbps. In addition to Ethernet, the 1756-L81E standard controller can also communicate via DeviceNet, ControlNet, Data Highway Plus, Synchlink, and remote I/O networks, as well as various third-party networks. This controller has 3 MB of user memory and can be installed in any available slot in the system chassis.

      ControlLogix's latest and most advanced product family. It is a programmable automation controller (PAC) with modern connectivity and functionality, serving as a migration platform for legacy controllers such as the PLC5 and SLC500, and meeting the demands of demanding industrial applications.

      The 1756-L81E Allen Bradley Controller module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Allen Bradley 1756-L81E Controller module Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      The 1756-L81E is the entry-level product in the 1756-L8 series of controllers, equipped with only 3 MB of user memory and 2 GB of non-volatile memory (implemented via a 1784-SD2 Secure Digital (SD) card). This controller can handle up to 128,000 discrete input/output signals and 4,000 analog input/output signals. Furthermore, it employs an environmentally friendly energy storage solution that provides backup for the controller's RAM without the need for batteries.
      This controller is designed for demanding industrial environments requiring high-speed data throughput and precise motion control:
      High-Speed ​​Motion Control: Supports integrated motion control of up to 256 axes via EtherNet/IP, making it ideal for packaging lines, robots, and complex assembly systems.
      Discrete Manufacturing: Suitable for high-speed assembly and material handling in smart factories, where rapid I/O processing (up to 128,000 digital points) is critical.
      Process Automation: Utilizes the PlantPAx process library for chemical, pharmaceutical, and food ingredient systems.
      Safety-Critical Systems: Can be used for SIL 2/PLd safety applications or in conjunction with safety partners to meet SIL 3 requirements.
      Modernization Platform: Can serve as an upgrade path for legacy PLC-5 and SLC 500 systems, enabling older plants to upgrade to modern gigabit connectivity.

      Manuals

      Technical notes

      The Allen-Bradley 1756-L81E is a high-performance programmable automation controller (PAC) belonging to the ControlLogix 5580 series. It features 3 MB of user memory, a built-in 1 Gbps Ethernet port, and a USB port for local programming. Supporting up to 60 Ethernet nodes and 128,000 I/O points, this controller employs a battery-free built-in energy storage module (ESM) design and features digitally signed firmware and integrated CIP security features. It is designed to provide stable support for high-speed I/O throughput, motion control, and data acquisition in medium to large industrial environments.
