Features:
- Allen-Bradley 1766-L32AWA is a MicroLogix 1400 controller with twenty 120 V AC digital inputs, four analog inputs, twelve relay outputs and two analog outputs.
- Match the L32AWA AC input/relay execution, 100/240 V AC supply, program, communications and expansion layout.
- Rockwell Automation MicroLogix 1400 Programmable Controllers Installation Instructions supports the exact-model values listed on this page.
Allen-Bradley 1766-L32AWA is a MicroLogix 1400 controller with twenty 120 V AC digital inputs, four analog inputs, twelve relay outputs and two analog outputs. It controls compact machines and process skids requiring mixed discrete and analog I/O.
Match the L32AWA AC input/relay execution, 100/240 V AC supply, program, communications and expansion layout. Before removal, record the nameplate, installed position, wiring or cables and approved settings. After installation, verify power and diagnostics first, then test every affected signal, communication or control path before return to service.
The Allen-Bradley 1766-L32AWA MicroLogix 1400 controller with AC inputs and relay outputs may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
1766-L32AWA documentation and reference links.
Important Notice: Confirm the complete catalog number, receiving hardware, firmware or wiring configuration before replacement.
Map twenty AC inputs, four analog inputs, twelve relays and two analog outputs.
Restore Ethernet and serial settings used by HMI, programming and connected devices.
Load the approved project and verify data tables, I/O and operating mode.
