Features:
- Officially documented 123447-01 TDXnet sampler circuit board.
- Provides two dynamic channels per installed sampler card.
- Supports synchronous and asynchronous waveform acquisition in the 2155/00 processor.
PWA123447-01 is the spare TDXnet sampler circuit board identified in the 2155/00 ordering documentation. One sampler card adds two dynamic channels, and the complete processor may contain up to twelve cards for twenty-four dynamic channels.
The sampler path acquires DC-coupled synchronous and asynchronous waveforms used for high-resolution static, orbit and spectrum information. Before replacement, preserve the exact slot assignment, associated static and dynamic cabling and channel configuration, then compare the results with the pre-work baseline.
The PWA123447-01 Bently Nevada TDXnet Sampler Circuit Board may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada PWA123447-01 documentation and reference links.
Important Notice: The first link is the official TDXnet specification and ordering document covering this configuration or documented spare part. Confirm the complete part number, revision, installed system and required accessories before replacement.
PWA123447-01 is the TDXnet sampler circuit board identified in the official 2155/00 ordering information. It acquires the dynamic signals used for synchronous and asynchronous waveform records.
Each sampler card supplies two dynamic channels. The complete 2155/00 order code defines the number of cards and each installed slot pair, so the replacement board must be returned to the recorded position.
Preserve static and dynamic cable routing, board revision, slot identity and channel configuration. After installation, compare steady-state, orbit, spectrum and startup/shutdown data with the pre-work baseline.
