Features:
- Four proximity-transducer channels can be configured for radial vibration, thrust position, eccentricity, differential expansion or REBAM measurements in the 3500 rack.
- Each front channel provides a short-circuit-protected buffered transducer output, while OK, TX/RX and Bypass LEDs support module-level operating checks.
- The direct signal path offers documented 4 Hz-4 kHz and 1 Hz-600 Hz filter selections, with channel programming and the matched rear I/O governing final use.
3500/40M 140734-01 is a legacy part reference for the Bently Nevada 3500/40M four-channel Proximitor monitor family. The monitor accepts signals from one to four proximity transducers and conditions each channel according to the configured measurement type. Supported functions include radial vibration, thrust position, eccentricity, differential expansion and REBAM, with configuration and I/O hardware determining the available channel arrangement. The module compares conditioned values with alarm setpoints and communicates essential machine information to the 3500 rack. Front OK, TX/RX and Bypass indicators report module status, while a protected coaxial connector for each channel provides buffered transducer access. The standard signal path supports the documented 4 Hz to 4 kHz or 1 Hz to 600 Hz direct-filter choices. Selection must match the front-module part number, rear I/O module, transducer system, rack configuration and channel programming. Current 3500/40M hardware uses a later front-module reference, so 140734-01 replacement requires an exact compatibility review.
Bently Nevada 3500/40M Proximitor Monitor Datasheet 141535. Current series data is used; verify legacy part 140734-01 against the installed module label.
The Bently Nevada 3500/40M 140734-01 is supported by Moore Automated for exact-item replacement and spare-part enquiries.
Bently Nevada 3500/40M 140734-01 Proximitor monitor manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Configure each of the four channels for the exact measurement required. Radial vibration, thrust position, eccentricity, differential expansion and REBAM use different signal processing and alarm considerations.
The front monitor does not define the complete field termination. Identify the rear I/O module, internal or external termination and transducer type before ordering a replacement or moving wiring.
Record the rack slot, configuration file, channel full-scale range, filter choice and alarm settings. Validate OK, TX/RX and Bypass status after the replacement is downloaded and verified.
