The General Electric IS200EHPAG1DAB is a exciter gate pulse amplifier board for GE Mark VIe industrial automation applications. Documented product details include Excitation Control system; Silicon Controlled Rectifiers; Industrial automation system. Confirm the complete model code, hardware revision and supplied condition against the installed equipment before replacement.
Verify that the supplied item is marked IS200EHPAG1DAB and that its exciter gate pulse amplifier board form, connectors and revision agree with the approved GE Mark VIe receiving record.
For IS200EHPAG1DAB, state the required condition, quantity, installed position, connected assemblies and document requirements in the written enquiry.
Apply only parameters supported by the exact IS200EHPAG1DAB record or a documented family source. Do not infer electrical ratings or interchangeability from appearance.
IS200EHPAG1DAB technical scope: Type: Exciter Gate Pulse Amplifier Board; Input Power: 125 V DC; Operating Temperature: -10°C to +70°C; Supply Voltage: +24 VDC or +125 VDC; Isolation Voltage: ≥2500 VAC.
Use these values only for the listed hardware execution and verify the supplied label before installation.
Match IS200EHPAG1DAB to the approved GE Mark VIe receiving position, connector or terminal arrangement and configuration record.
After power restoration, review diagnostics and test the affected exciter gate pulse amplifier board path.
Active / Available from OEM
IS200EHPAG1DAB is a General Electric exciter gate pulse amplifier board associated with the GE Mark VIe platform. It supports the documented control, interface or signal-processing duty assigned to its installed board position. Correct selection depends on the complete model code, connector or terminal arrangement, hardware revision and receiving-system configuration. Before replacement, compare the original product label, installed slot or cabinet reference, connected assemblies and approved project records. After installation, review system diagnostics and function-test every affected channel, control path, protection function or communication link before returning the equipment to service.
