      ABB RPBA-01
      ABB RPBA-01

      • ISO 9001:2015 Certified

        Our quality management system covers sourcing,testing and dispatch

      • View Our Success Stories

        Real stories from real customer orders
      In Stock
      Ships by Monday, September 21
      Fast Shipping Available
      PROFIBUS DP fieldbus adapter module

      RPBA-01

      Spare Part Number

      PN3ABD64606859

      Product Information:

      ABB RPBA-01 is a PROFIBUS DP slave adapter module for compatible ACS550, ACH550, ACS800, ACQ800 and DCS800 drives. It supports DP and DP-V1 communication, automatic baud-rate detection from 9.6 kbit/s to 12 Mbit/s, PPO types 1-6 and PROFIdrive or ABB Drives profiles. Installation is in the specified drive option slot and requires the complete module identity 3ABD64606859 to match the installed drive hardware.


      Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote
      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs
        • PRODUCT OVERVIEW

          What is this product?

          ABB RPBA-01, article 3ABD64606859, is a drive-mounted PROFIBUS DP slave adapter for compatible ACS550, ACH550, ACS800, ACQ800 and DCS800 products. ABB documents DP and DP-V1 communication, automatic baud-rate detection up to 12 Mbit/s, PPO types 1-6 and PROFIdrive or ABB Drives profiles. The module installs in the specified drive option slot and must be matched by complete article number, drive family and network configuration.

          Official source

          ABB RPBA-01 User’s Manual, revision F, and ABB legacy fieldbus adapter product information.
        • APPLICATIONS

          Where it may be used

          Use RPBA-01 where a documented ABB drive must operate as a PROFIBUS DP slave. Confirm the host drive, option-slot position, GSD selection, node address and termination before commissioning.

          ACS550 Network Integration

          Adds PROFIBUS DP communication through the documented slot 2 arrangement.

          ACS800 Fieldbus Retrofit

          Restores the installed PROFIBUS interface in the specified option slot.

          PROFIdrive Control

          Supports standard cyclic control and status exchange with PPO types 1-6.

          DP-V1 Diagnostics

          Enables documented acyclic services and diagnostic access on compatible drives.
      Technical specifications for

      RPBA-01

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        ABB
      • Product Category:
        Inverter Drives
      • Spare Part Number:
        3ABD64606859
      • Product Type:
        PROFIBUS DP adapter module
      • Network Role:
        PROFIBUS DP slave
      • Supported Protocol:
        DP and DP-V1
      • Compatible Drives:
        ACS550, ACH550, ACS800, ACQ800 and DCS800
      • PROFIBUS Data Rates:
        9.6 kbit/s to 12 Mbit/s, automatically detected
      • PPO Types:
        1 to 6, automatically detected
      • Communication Profiles:
        PROFIdrive and ABB Drives
      • GSD Files:
        ABB_0812.GSD (DP-V0) and ABB10812.GSD (DP-V1)
      • Node Address Range:
        0 to 126; rotary switches provide 00 to 99
      • Bus Termination:
        Integrated, DIP-switch controlled
      • Maximum Cyclic I/O:
        28 bytes in / 28 bytes out
      • Maximum Acyclic I/O:
        240 bytes in / 240 bytes out
      • Degree of Protection:
        IP20
      • Mounting:
        Drive option slot; ACS550 slot 2 or ACS800 slot 1
      • Connectors:
        34-pin parallel bus and 9-pin female D-sub
      • Current Consumption:
        350 mA maximum at 5 V DC
      • Stock Availability:
        6
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      RPBA01 RPBA 01 ABB RPBA-01 64606859

      Information

      Overview Manuals Network Setup Drive Compatibility Commissioning

      Features:

      • Automatically detects PROFIBUS baud rates from 9.6 kbit/s to 12 Mbit/s and supports the documented DP and DP-V1 communication services with the applicable ABB GSD file.
      • Supports PROFIdrive and ABB Drives profiles, PPO types 1–6, cyclic I/O up to 28 bytes in each direction and DP-V1 acyclic I/O up to 240 bytes in each direction.
      • Provides integrated DIP-switch bus termination, node addressing from 0 to 126, a 34-pin drive bus interface and a 9-pin female D-sub PROFIBUS connection for the documented ABB drive option slot.

      ABB RPBA-01 3ABD64606859 is a drive-mounted PROFIBUS DP slave adapter for compatible ACS550, ACH550, ACS800, ACQ800 and DCS800 products. It must be selected by complete article number, host-drive family, option-slot position, communication profile and installed network configuration.

      Official source: ABB RPBA-01 User’s Manual, revision F. Official PROFIBUS DP adapter specifications and installation data.
      ABB RPBA-01 3ABD64606859 PROFIBUS DP adapter Manuals / Datasheets / Links Important Notice: Other accessories, manuals, cables, calibration data, software, licenses and related items are not included unless listed in the stock item description. All prices are shown in USD.

      PROFIBUS addressing and rate selection: RPBA-01 supports node addresses 0–126; the two rotary switches set addresses 00–99 and parameter-based addressing is used above 99. The module detects the documented PROFIBUS baud rate automatically and the two network ends must be terminated.

      Documented ABB drive families: The RPBA-01 manual covers ACS550, ACH550, ACS800, ACQ800 and DCS800 drive installations. Confirm the host drive, control-board option slot, selected communication profile and the required GSD file before replacement.

      Configuration checkpoints: Match the PROFIBUS node address, DP or DP-V1 mode, PPO type, profile and cyclic process-data mapping to the master configuration. Verify the diagnostic LEDs and fieldbus parameters before enabling drive control.

      Technical notes

      ABB RPBA-01 is a PROFIBUS DP slave adapter identified by article number 3ABD64606859. The official manual documents DP and DP-V1 operation, automatic baud-rate detection through 12 Mbit/s, PPO types 1-6, PROFIdrive and ABB Drives profiles, integrated termination and defined option-slot mounting. Confirm the complete article number, drive model, control-board option slot, node address and existing PROFIBUS connector arrangement before replacement.

      Exact Module and Drive Verification

      Confirm the complete identity RPBA-01 / 3ABD64606859, the module label, installed drive model, control-board option slot and PROFIBUS connector before quotation. If any suffix or marking is unclear, provide a clear nameplate photograph so Moore Automated can match the exact ABB fieldbus adapter.

      Quotation Details for RPBA-01

      Please provide the required quantity, complete RPBA-01 article number, module and drive nameplate photographs, host drive model, receiving country and required delivery date. These details allow Moore Automated to verify compatibility, inspection scope and the exact supply condition before issuing a quotation.

      Customs & shipping dimensions / weight

      • Packed shipping dimensions
        Confirmed after final packing
        Module enclosure: 95 × 34 × 62 mm plus 20 mm projection (ABB manual).
      • Packed shipping weight
        Confirmed after final packing
        Confirmed by actual-item weighing before shipment.
      • HS / customs code
        85049099
        Functional classification for a static-converter part; verify destination tariff requirements.
      • Country of origin
        Not officially confirmed
        Verify from the supplied item nameplate or certificate of origin.
      • Ships from
        Xiamen, Fujian, China
        Dispatch location is confirmed in the written quotation.
      • Customs documents
        Confirmed for the destination
        Available document scope is stated in the written quotation.
      PRODUCT & ORDER FAQS

      Questions buyers ask about RPBA-01

      • What is ABB RPBA-01 3ABD64606859?

        It is an ABB PROFIBUS DP slave adapter module that connects a compatible drive to a PROFIBUS DP network and supports both DP and DP-V1 communication.

      • Which drives are documented for RPBA-01?

        ABB lists ACS550, ACH550, ACS800, ACQ800 and DCS800 compatibility. The exact drive type, control board and option-slot arrangement must still be confirmed.

      • What data rates does the module support?

        The official user manual lists 9.6, 19.2, 45.45, 93.75, 187.5 and 500 kbit/s plus 1.5, 3, 6 and 12 Mbit/s, with automatic detection.

      • How should RPBA-01 be installed?

        Isolate the drive, verify the correct option slot and connector orientation, set the node address and termination as required, then commission the network according to ABB instructions.

      • Can Moore Automated confirm stock for 3ABD64606859?

        Yes. Available quantity, supplied condition and inspection scope are confirmed in the written quotation before order placement.

      • What warranty is supplied with this ABB adapter?

        Moore Automated provides a one-year warranty; the supplied condition and warranty scope are stated in the quotation.

      • How quickly can RPBA-01 be shipped?

        The listing uses a three-day fast-dispatch target. Final timing depends on quantity, inspection completion and destination.

      • Which documentation supports the specifications?

        The data comes from ABB RPBA-01 User’s Manual, revision F, including the technical data and supported-drive sections; the internal Manuals tab opens the uploaded ABB PDF.
