In terms of power consumption
Features:
- Input module from ControlLogix series accommodates various input configurations for robust data handling
- Designed to support advanced measurement needs, it functions effectively with different voltage and current inputs
- 8 single-ended inputs, 4 differential inputs, 2 high-speed differential inputs
The Allen Bradley 1756-IF8 is an input module designed specifically for ControlLogix sensor series. This module offers multiple input configurations, including eight single-ended inputs, four differential inputs, and two high-speed differential inputs. This wide input range allows for flexible monitoring of various signal types.
For current input, the module supports a current range of 0 to 20 mA, compatible with various sensor types. For voltage input, it can accurately handle voltage values from -10 to 10V, 0 to 10V, or 0 to 5V. The module has low power consumption, consuming 150 mA with a 5.1V DC supply and 40 mA with a 24V DC supply, with a total backplane power consumption of only 1.73 watts.
The 1756-IF8 Allen Bradley Analog input module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen Bradley 1756-IF8 Analog input module Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The module consumes 1.73 watts in voltage mode and 2.33 watts in current mode. The device has an input impedance of 1 megohm in voltage mode and 249 ohms in current mode, ensuring compatibility with standard sensors. Furthermore, onboard data alarms and real-time channel sampling enhance its application value, while the employed Σ-Δ conversion method improves the accuracy and reliability of signal processing.
