- Allen-Bradley 1762-OA8 is an eight-point 120/240 V AC triac output module for MicroLogix expansion I/O.
- Match the AC voltage category, two output groups, load current and inrush, suppression and expansion-power budget.
- Rockwell Automation MicroLogix 1200 Programmable Controllers User Manual supports the exact-model values listed on this page.
Allen-Bradley 1762-OA8 is an eight-point 120/240 V AC triac output module for MicroLogix expansion I/O. It switches AC solenoids, relays and indicators from a supported MicroLogix controller.
Match the AC voltage category, two output groups, load current and inrush, suppression and expansion-power budget. Before removal, record the nameplate, installed position, wiring or cables and approved settings. After installation, verify power and diagnostics first, then test every affected signal, communication or control path before return to service.
The Allen-Bradley 1762-OA8 eight-point AC triac output module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
1762-OA8 documentation and reference links.
Important Notice: Confirm the complete catalog number, receiving hardware, firmware or wiring configuration before replacement.
Confirm the connected load meets triac leakage and minimum-current requirements.
Wire VAC0 and VAC1 groups according to the published terminal diagram.
Include 115 mA at 5 V and 2.9 W dissipation in the system budget.
