Features:
- CPU controller module
- MicroLogix 1400 Controller under the Bulletin 1766 product family
- 12 Fast 24V DC Inputs 8 Normal 24V DC Inputs 12 Relay Outputs
MicroLogix 1400 Controller under the Bulletin 1766 product family. This compact controller features integrated Three (3) communication ports such as a combo RS232 / RS485 port, isolated RS232 port and an Ethernet communication port. It has embedded Input and Output channels which consists of Twenty (20) digital 120V AC inputs, Four (4) 0-10VDC analog inputs, Twelve (12) Relay outputs and Two (2) 0-10VDC analog outputs.
It comes with the EtherNet/IP network, online editing capabilities, and a built-in LCD with enhanced network capabilities. There is also a backlight on the LCD to set the network configuration and view the controller and I/O status. The 1766-L32BWAA controller requires 120 to 240 Volts AC input power and it has battery-backed RAM.
The 1766-L32BWAA Allen Bradley Controller Modules may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen Bradley 1766-L32BWAA CPU Modules Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
It is suitable for use in a clean and dry industrial environment with circuits not exceeding Over-Voltage Category II. The 1766-L32BWAA controller comes with an Ethernet port that provides DNP3 protocol support as well as a web server and email capabilities. It has 2 Serial ports with DH485/DF1/Modbus RTU/DNP3/ASCII protocol support, up to 6 embedded 100 kHz high-speed counters, and a 20 KB memory for user programs and data.
