Features:
- The complete code identifies a 33 ft (10.06 m) factory-defined cable length rather than a generic cut cable.
- Two twisted shielded 22 AWG conductors connect the moisture-resistant two-socket sensor plug to terminal lugs.
- Stainless-steel armor and the documented -50-to-+120 °C range support properly routed industrial installations.
Bently Nevada identifies 84510-33 as a 33 ft (10.06 m) armored cable configuration used with the documented 9200/74712 Seismoprobe velocity-transducer interface. The cable contains two twisted shielded 22 AWG conductors, a two-socket moisture-resistant female connector at the sensor end and terminal lugs at the receiving end. Stainless-steel armor protects the field route, but the armor does not replace correct support, bend control or environmental sealing. The manufacturer documents an operating range of -50 to +120 °C and length ordering in one-foot increments. The exact cable family, length code, connector condition, transducer model and receiving-channel wiring must all be checked because cables that look similar may use a different temperature rating or system interface.
Manufacturer reference: official 9200/74712 Seismoprobe cable accessories documentation.
Moore Automated supports exact-item verification and spare-part enquiries for 84510-33.
Bently Nevada 84510-33 High-temperature armored cable manual (Datasheet), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Confirm the 33 ft route, service loop and connector access before selecting the ordered length.
Verify the two-socket sensor plug, lug-terminated panel end, conductor identification and shield treatment against the existing drawing.
Support the stainless-steel armor, avoid crushing and tight bends, and protect both terminations from pull or impact.
