Features:
- Honeywell identifies 51198651-100 as the current Version 3 silver power supply for supported PM, APM, HPM, EHPM, EHPMX and C300PM power-system maintenance.
- The current module replaces the listed 51109684-100/300, 51198947-100 and obsolete 51109456-200 supply references, subject to verification of the installed assembly.
- Honeywell recommends a ten-year preventive replacement interval and off-process service where possible, with power, grounding and redundancy checks completed before restart.
SPS5785 51198651-100 is a Honeywell power-supply module for supported xPM-family control-system power assemblies. Honeywell's current service guidance identifies 51198651-100 as the Version 3 silver supply and the recommended replacement for listed earlier silver and black supply references, including 51109684-100/300, 51198947-100 and 51109456-200. The documented power-system scope covers PM, APM, HPM, EHPM, EHPMX and C300PM platforms. Honeywell recommends preventive replacement of these power supplies at ten-year intervals to reduce age-related failures. Replacement should preferably be performed off-process and must preserve the engineered redundancy, power and grounding arrangement. Front indicators provide the documented DC Output, Battery, Common, Fan/Temp, AC In and Charging status references. Selection requires the complete 51198651-100 label, the installed power-system type and a check of the existing supply references rather than appearance alone.
Honeywell Process Solutions 2025 System Hints and HPM service documentation. The source identifies 51198651-100 as the current silver power-supply replacement for listed earlier xPM supplies.
The Honeywell SPS5785 51198651-100 is supported by Moore Automated for exact-item replacement and spare-part enquiries.
Honeywell SPS5785 51198651-100 HPM power supply module manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Confirm the front and side labels show SPS5785 and 51198651-100. Compare the installed supply reference because older black and silver modules have different part numbers even when they occupy the same power-system role.
Honeywell recommends replacing xPM-family power supplies after ten years and prefers off-process work. Preserve system redundancy, grounding and the documented service sequence during exchange.
Record the DC Output, Battery, Common, Fan/Temp, AC In and Charging indications before and after replacement. Use these observations with the system maintenance procedure; LEDs alone do not replace electrical safety checks.
