      6EP1334-3BA10

      Power supply Module

      Product Information

      Product Describe

      SITOP PSU200M

      output: 24 V DC/10 A

      input: 120/230-500 V AC

      10 A stabilized power supply

      • Manufacturer:
        Siemens
      • Product Category:
        PLC System
      • Estimated shipping dimensions:
        7x12.5x12.1cm
      • Weight:
        0.8 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        Germany
      • Place of shipment:
        Xiamen, Fujian, China
      • supply voltageovervoltag:
        at AC 120 ... 230 V
      • input voltage:
        at AC 85 ... 264 V
      • overvoltage overload capability:
        1300 Vpeak 1.3 ms
      • line frequency:
        47 ... 63 Hz
      • input current:
        at rated input voltage 120 V 4.4 A
      • output voltage at DC rated value:
        24 V
      • adjustable output voltage:
        24 ... 28.8 V
      • residual ripple:
        maximum 50 mV
      • voltage peak:
        maximum 200 mV
      • Stock:
        30
      By purchasing this item, you agree to the Terms & Conditions
      Moore Automated is NOT an authorized distributor of Siemens
      right background
      1-year warranty

      All our products come with a 1-year warranty for your peace of mind.

      Service means taking a customer problem and making it your own challenge. Years of experience and listening skills enable us to think and act quickly and accordingly. You have a problem? – We have the solution!
      Moore Automated is not an authorized distributor, reseller or representative of the products featured on this website.
      All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
      Learn More Policy
      Manuals
      • Order Online:
        We have been working hard to update our inventory.

        If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show “Ask”. Please create an online quote or contact us by phone, fax or email to check availability.
      • Order by:
        You can also contact us by phone, fax or email to order. We are here to help you!
      • E-mail:
        We need the following information to process your order quickly and accurately: Your complete ship and receipt information
      • Delivery:
        How do you want to ship? Shipping information
      • Payment:
        How will you pay? Payment procedure
      Learn More Policy
      Quantity*
      Mobile*
      Company
      E-mail*
      Content*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote

      Quick Search

      • Part or Model Number

        • Please try to be as accurate as possible with your search.
        • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
        • We can't find any results for “”.
          SEE MORE
            SEE PRODUCTS IN SEARCH PAGE ()

          • Filter by Manufacturer

          • Filter by Category

          Featured Manufacturers

          FAQ

          • What is the primary power conversion function of the 6EP1334-3BA10 within industrial control systems?
            The 6EP1334-3BA10 is a modular SITOP PSU200M stabilized AC/DC power supply that converts a wide-range AC mains input into a controlled, regulated 24 V DC output capable of delivering up to 10 A, suitable for supplying PLCs, sensors, and actuators in industrial automation environments.
          • What input voltage configurations does the 6EP1334-3BA10 support, and how are they selected?
            The 6EP1334-3BA10 accepts either single-phase or two-phase AC input, selectable via a built-in selector switch. It supports a wide operating range of 85…264 V AC or 176…550 V AC, enabling operation from typical low-voltage single-phase mains up to direct connection across higher-voltage feeds.
          • How does the line frequency and buffering capability of the 6EP1334-3BA10 enhance its performance under fluctuating mains conditions?
            The 6EP1334-3BA10 is engineered for an AC line frequency range of 47…63 Hz, accommodating global mains standards. It provides mains buffering of at least 25 ms at rated output, with typical buffering of ~150 ms at standard voltages, which helps maintain stable 24 V output during transient dips or brief mains interruptions.
          • What output regulation performance can be expected from the 6EP1334-3BA10?
            The 6EP1334-3BA10 delivers a regulated 24 V DC output with a static tolerance of about ±3 %. The output can be fine-tuned via an integrated potentiometer (24…28.8 V) to accommodate specific load requirements, with excellent compensation against slow input or load fluctuations (~0.1 %).
          • How does the 6EP1334-3BA10 signal operational status and fault conditions?
            Operational status for the 6EP1334-3BA10 is communicated via a green LED indicator for “24 V OK.” Additionally, a normally-open relay contact provides a remote “DC voltage OK” signal (contact rated for low-voltage signaling applications).
          • What are the environmental and mechanical deployment parameters for the 6EP1334-3BA10?
            Mechanically, the 6EP1334-3BA10 mounts on standard DIN rail (EN 60715) and measures approximately 70 × 125 × 121 mm, weighing around 0.8 kg. It is rated for industrial ambient temperatures from –25 °C to +70 °C, with broader transport and storage tolerances.
          • What industrial certifications and compliance attributes are associated with the 6EP1334-3BA10?
            The 6EP1334-3BA10 holds multiple industry-recognized certifications, including CE, UL, CSA, EAC and EMC protections like EN 55022 Class B and EN 61000-6-2, ensuring its suitability for demanding automation environments.
