      SD853 3BSE088188R1

      Power Supply Module
      In Stock

      Product Information:

      SD853 Power Supply 10A

      designed for high efficiency, electronic

      inrush current limitation, wide operating

      temperature range, and extraordinarily

      small size

      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for SD853 3BSE088188R1

      • Manufacturer:
        ABB
      • Product Category:
        DCS System
      • Estimated shipping dimensions:
        3.9 x 11.7 x 12.4 cm
      • Weight:
        0.6 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        sweden
      • Place of shipment:
        Xiamen, Fujian, China
      • Rated output current:
        10 A
      • Rated output power:
        240 W
      • Rated output voltage:
        24 V d.c.
      • Mains/input voltage, nominal:
        100-240 V a.c. 110-150 V d.c.
      • Mains frequency:
        50 - 60 HZ +/- 6%
      • Output voltage regulation at max. current:
        max 50 mV 0 - 12 A
      • Output over voltage protection:
        Max 32 V DC
      • Electrical safety:
        IEC 60950-1
      • Protection rating:
        IP20 according to IEC 60529
      • Stock:
        30
      Ask for Quote

      Information

      Overview Manuals Features and benefits Primary Applications

      Features:

      • DIN-rail mounting, Width 39 mm
      • Active Power Factor Correction (PFC)
      • Easy Fuse Breaking due to High Overload Peak Current
      • Temperature range -25°C and +70°C (derating 6W / °C between 60°C - 70°C)
      The SD85x Power supply units are designed for high efficiency, electronic inrush current limitation, wide operating temperature range, and extraordinarily small size. The lowest power losses and high lifetime expectancy deliver the lowest cost of ownership.

      The SD85x series complies for use in potentially explosive atmospheres (IECEx Zone 2, ATEX Zone 2, and Class I Div 2). The SD85x series has a built-in power reserve and can easy breaking fuses due to high overload peak current capability.

      The SD853 3BSE088188R1 ABB Power supply module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      ABB SD853 3BSE088188R1 Power supply module Manual(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      • Efficiency up to 95.2 %
      • 20% Output Power Reserves
      • Minimal Inrush Current Surge
      • DC-OK Relay Contact
      • Class I Div 2, IECEx Zone 2 and ATEX Zone 2
      1. DCS and Control Systems: It is a key component providing 24V DC power to ABB's flagship control platforms, including System 800xA, Symphony Plus, and Freelance.
      2. I/O Power Supply: Dedicated to powering the S800 I/O and Select I/O modules, ensuring reliable data acquisition and control signals.
      3. Hazardous Environments: Due to its ATEX Zone 2, IECEx Zone 2, and Class I Div 2 certifications, it is commonly used in flammable and explosive industries such as oil and gas or chemical industries.
      4. Redundant Configuration: Can be used with relevant voting units to build redundant power systems, which is crucial for maintaining "always-on" operation in power plant or marine environments (DNV-GL and ABS certified).

      Manuals

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • How does the SD853 3BSE088188R1 meet the IEC-compliant electrical performance parameters and internal circuitry stability requirements outlined in its technical specifications?
        The SD853 3BSE088188R1 meets the electrical constraints specified in the datasheet, such as voltage regulation tolerance, current handling threshold, and internal signal integrity requirements, to ensure deterministic operation in a controlled environment.
      • What are the thermal characteristics and environmental thermal resistance of the SD853 3BSE088188R1 under continuous operating load conditions?
        The SD853 3BSE088188R1 maintains thermal stability through a controlled heat dissipation path, ensuring compliance with the specified operating temperature range and preventing performance degradation under continuous load conditions.
      • How does the SD853 3BSE088188R1 ensure electromagnetic compatibility (EMC) and noise immunity in high-interference industrial environments?
        The SD853 3BSE088188R1 is designed using EMC suppression strategies defined in the datasheet, including shielding principles, filtering mechanisms, and grounding architecture, to minimize susceptibility to electromagnetic interference.
      • What reliability engineering standards and lifecycle performance metrics does the SD853 3BSE088188R1 adhere to in terms of operational durability?
        The SD853 3BSE088188R1 is evaluated using the reliability model specified in the datasheet, including Mean Time Between Failures (MTBF) calculation, failure rate analysis, and accelerated lifecycle testing under simulated industrial stress conditions.
      • How does the SD853 3BSE088188R1 maintain operational integrity under voltage fluctuations, load changes, and transient disturbances?
        The SD853 3BSE088188R1 integrates transient suppression, power supply stabilization, and fault-tolerant circuitry to ensure functional continuity under unstable electrical conditions.
      • The SD853 3BSE088188R1 datasheet states that it complies with which industry certification frameworks and regulatory standards?
        The SD853 3BSE088188R1 generally complies with industry regulatory frameworks such as CE, RoHS, and relevant IEC standards to ensure compliance with global safety, environmental, and operational requirements.
