AI845 is an ABB analog input module selected by its complete product identity and documented equipment role. Its verified data includes Signal specification 0..20mA, 4..20 mA, 0..5 V, 1..5 V; Number of channels 8; Signal type Unipolar single ended; Redundancy Yes; Resolution 12 bit. Correct selection depends on the installed hardware, interfaces and approved system configuration rather than appearance alone.
Before installing AI845, record the original nameplate, installed position, connected assemblies and relevant settings. Compare the supplied unit with the approved ABB documentation, isolate affected energy sources and complete controlled functional checks before returning the equipment to service.
The AI845 ABB Analog Input Module is listed as Active / Available from OEM. Current revision, availability and supplied scope are confirmed in the written quotation.
ABB AI845 documentation and reference links.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
AI845 performs the documented analog input module function within the Advant S800 I/O platform. Verified product data includes Signal specification 0..20mA, 4..20 mA, 0..5 V, 1..5 V; Number of channels 8; Signal type Unipolar single ended; Redundancy Yes; Resolution 12 bit; Input impedance 10 MΩ (voltage input) 250 Ω (current input). These values and the complete hardware revision must match the supplied unit.
Integrate AI845 only with the approved Advant S800 I/O receiving hardware, connector or terminal arrangement and paired assemblies. Preserve all recorded settings, then verify each affected interface and diagnostic path after installation.
Before energizing AI845, inspect mounting, connector keying, wiring allocation, protective grounding and connected equipment. Review status indications and diagnostics, then complete controlled functional tests before service release.
