- ABB identifies TC810, article 3BSE076220R1, as a copper Ethernet adapter with a built-in two-port switch and two RJ45 ports. It is used with CI845 and TU860 in single or redundant arrangements.
- Match TC810 article, CI845/TU860 hardware, RJ45 port allocation, redundant network design, 24 V supply and grounding.
- Verify both Ethernet links, switch forwarding, CI845 communication and the engineered redundancy path.
TC810 must be selected from the complete manufacturer identity and the receiving-system evidence. Use it as the documented copper-media adapter in the Ethernet FCI station. Keep the network A/B paths distinct, observe the 100 m cable limit and restore shield and grounding practice.
Official source: ABB S800 I/O communication-interface data sheet. 3BSE076220R1 identity, two RJ45 ports, 100BASE-TX, 100 m limit, power and environmental values.
TC810 official technical documentation and related ABB resources.
Important Notice: Confirm the complete article number and installed configuration before replacement. Each link opens in a new page.
TC810 provides two RJ45 copper ports and a built-in Ethernet switch.
Use the adapter only with the documented CI845/TU860 single or redundant assembly.
After cabling, verify link indicators, port assignment, FCI communication and redundancy.
