ABB NTHS03 is a hydraulic servo termination unit for Harmony Rack and INFI 90 control-system hardware. Its role is defined by the connected module, cable and field or network circuits.
Replacement requires confirmation of the complete model, revision, module pairing, terminal assignments and cabinet installation rather than selection by appearance alone.
The ABB NTHS03 may be supplied and supported by Moore Automated according to the stated manufacturer lifecycle and confirmed stock condition.
ABB NTHS03 Hydraulic Servo Termination Unit Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Interface Functions:
- Hydraulic servo field termination
- SPHSS13 infrastructure compatibility
- NKHS03 cable interface
- LVDT feedback circuit termination
- Servo demand and output wiring
NTHS03 is the field termination unit associated with Harmony hydraulic servo control and the SPHSS13 evolution path. Verify NKHS03 cable selection, LVDT wiring, feedback polarity, servo-coil circuits, grounding and controller configuration before calibration.
System Compatibility:
- ABB documents NTHS03 as related hardware for SPHSS13 and the NKHS03 cable. Confirm compatibility with the installed IMHSS or SPHSS servo module and field devices.
- Match the module cable and hardware revision.
- Verify field or network wiring before commissioning.
It terminates hydraulic valve position feedback, demand and servo output circuits in turbine-control systems.
Installation Guidance:
- Isolate cabinet and field power before wiring.
- Preserve terminal identification and cable routing.
- Complete a functional check before process operation.
Secure the turbine and hydraulic system, label LVDT and coil circuits, match the NKHS03 cable, verify polarity and complete the documented servo calibration before operation.
