Features:
- The documented number of inputs is 8 independent channels.
- The documented input isolation is Optically isolated.
- The documented input types is 5/24 V contact or 50 mVpp to 10 Vpp.
SPDSM04 is an ABB 8-Channel Pulse Input Module selected by its complete product identity and documented equipment role. Suitability depends on the installed Bailey Infi 90 hardware, interfaces and application requirements matching the supplied unit.
Before replacement, record the nameplate, installed position, terminal or connector arrangement and paired assemblies. After installation, verify every affected power, communication, protection, control or I/O function before returning SPDSM04 to service.
The SPDSM04 ABB 8-Channel Pulse Input Module is listed as Active / Available from OEM. Current revision, availability and supplied scope are confirmed in the written quotation.
ABB SPDSM04 documentation and reference links.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SPDSM04 performs the documented 8-channel pulse input module function within the Bailey Infi 90 system. Confirm the recorded power, signal, communication and mechanical interfaces against the approved equipment record. Do not infer ratings or interchangeability from appearance; the complete label and hardware revision control selection.
Replacement of SPDSM04 requires an exact match to the receiving Bailey Infi 90 hardware, connected assemblies and configuration record. Record the installed position and connections before removal, preserve required settings, and verify every affected function after installation.
Before energizing SPDSM04, inspect mounting, connector keying, terminal allocation, protective grounding and paired equipment. After startup, review diagnostics and complete controlled functional tests before returning the equipment to service.
