Features:
- Synchronizing devices and systems
- Dual channel device Large size
- Redundant automatic dual-channel synchronizing system
The SYNCHROTACT 6 single-channel synchronizing devices, which are very often used, offer a high degree of safety. However, safety can be significantly increased by means of dual-channel systems with an independent synchrocheck connected in series.
It is unlikely that both channels, of which the hardware and software are structured differently, will suffer the same malfunction simultaneously. The extra cost of a dual-channel system can prove beneficial compared to the damage arising from incorrect paralleling.
The SYN 6302 3BHE056302R0203 ABB Synchronizing device may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SYN 6302 3BHE056302R0203 Synchronizing device Manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Maintenance control for commissioning and servicing
• Built-in Maintenance Control Panel (MCP)
• SynView 6 PC-tool
Operating control for normal synchronizing operation
• Binary inputs/outputs: conventional wiring (standard)
• Communication interfaces: IEC 61850 electrical or optical;
Modbus RTU; Profibus DP (option)
The SYN 6202 is a dual-channel system with two differently structured independent channels used as one functional system.
SYN 6302 consists of two “SYN 6202” dual-channel devices used as a redundant system. The output contacts of both devices are normally wired in series (four channels!). If one device fails, a safe switchover to the other device is possible by bypassing it. This allows paralleling to be carried out fully automatically and with maximum safety at all times.
If repair or replacement of the defective device is needed, it can easily be removed from the system.
Remark: the simpler SYN 5100 from the SYNCHROTACT 5
family is not replaced. It can however be used in combination
with the SYNCHROTACT 6 devices.
