Features:
- Allen-Bradley 1769-PA2 is an 85–265 V AC Compact I/O power supply rated for 2.0 A at 5 V and 0.8 A at 24 V on the backplane.
- Match the PA2 AC input, bus-current demand, eight-module distance rule, bank layout, grounding and fusing.
- Rockwell Automation CompactLogix Power Supplies Specifications supports the exact-model values listed on this page.
Allen-Bradley 1769-PA2 is an 85–265 V AC Compact I/O power supply rated for 2.0 A at 5 V and 0.8 A at 24 V on the backplane. It powers a CompactLogix controller bank or additional 1769 I/O bank within the documented load limits.
Match the PA2 AC input, bus-current demand, eight-module distance rule, bank layout, grounding and fusing. Before removal, record the nameplate, installed position, wiring or cables and approved settings. After installation, verify power and diagnostics first, then test every affected signal, communication or control path before return to service.
The Allen-Bradley 1769-PA2 Compact I/O AC power supply may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
1769-PA2 documentation and reference links.
Important Notice: Confirm the complete catalog number, receiving hardware, firmware or wiring configuration before replacement.
Verify source voltage, frequency, upstream fuse, disconnect and protective earth.
Total 5 V and 24 V demand must remain within PA2 ratings and derating limits.
Keep modules within distance rating and place the supply correctly in each bank.
