      1746-OB32E

      SLC 500 Digital DC Output Module

      Product Information

      Product Describe

      SLC 500 Digital DC Output Module

      This Output Module has Thirty-Two

      (32) 24VDC, Electronically Protected

      output channels. It has Two (2) input

      groups with each group having

      Sixteen (16) points

      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC System
      • Spare Part Number:
        1746-0B32E, 1746-OB32E/A
      • Estimated shipping dimensions:
        12.7 cm x 5.1 cm x 15.2 cm
      • Weight:
        0.3 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Outputs:
        32 Outputs
      • Voltage Range:
        10-30 Volts DC
      • Current/Outputs:
        0.5 or 0.25 amps
      • Current/Module:
        8 amps
      • Nominal output:
        24VDC
      • Backplane Current:
        (5 Volts)190 mA
      • Step Response:
        60 milliseconds in, 2.5 milliseconds out
      • Signal Delay, ON:
        0.1 ms
      • Stock:
        30
      By purchasing this item, you agree to the Terms & Conditions
      Moore Automated is NOT an authorized distributor of Allen-Bradley
      right background
      1-year warranty

      All our products come with a 1-year warranty for your peace of mind.

      Service means taking a customer problem and making it your own challenge. Years of experience and listening skills enable us to think and act quickly and accordingly. You have a problem? – We have the solution!
      Moore Automated is not an authorized distributor, reseller or representative of the products featured on this website.
      All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
      Learn More Policy
      Manuals
      1746-OB32E.pdf
      • Order Online:
        We have been working hard to update our inventory.

        If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show “Ask”. Please create an online quote or contact us by phone, fax or email to check availability.
      • Order by:
        You can also contact us by phone, fax or email to order. We are here to help you!
      • E-mail:
        We need the following information to process your order quickly and accurately: Your complete ship and receipt information
      • Delivery:
        How do you want to ship? Shipping information
      • Payment:
        How will you pay? Payment procedure
      Learn More Policy
      Quantity*
      Mobile*
      Company
      E-mail*
      Content*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote

      Quick Search

      • Part or Model Number

        • Please try to be as accurate as possible with your search.
        • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
        • We can't find any results for “”.
          SEE MORE
            SEE PRODUCTS IN SEARCH PAGE ()

          • Filter by Manufacturer

          • Filter by Category

          Featured Manufacturers

          FAQ

          • How does the 1746-OB32E differentiate itself in terms of output configuration compared to non-E series modules?
            Unlike standard 1746-OB32 modules which operate over 5–50 V DC, the 1746-OB32E is designed for a 10–30 V DC output domain and includes on-board electronic protection against overload and short-circuit conditions, thereby improving module longevity and safeguarding connected loads.
          • In what voltage range must devices interfacing with the 1746-OB32E operate for reliable performance?
            Field devices connected to the 1746-OB32E should be compatible with the module’s operational output range of 10–30 V DC, ensuring predictable drive behavior and reducing risk of control anomalies.
          • How is isolation implemented to protect the SLC 500 system when using the 1746-OB32E?
            The 1746-OB32E module maintains 1,500 V AC isolation between the backplane logic and field circuits, which mitigates electrical disturbances and helps preserve logic integrity.
          • How does the 1746-OB32E module integrate into an SLC 500 rack, and are there any configuration considerations?
            The 1746-OB32E plugs into any available I/O slot in an SLC 500 chassis (excluding slot 0). It should be addressed correctly in the SLC configuration and ladder logic, and its common returns should be wired per system design best practices to preserve signal integrity.
