      1746-P6

      Power Supply Module
      In Stock

      Product Information:

      SLC 500 Power Supply

      This Power Supply has an Input

      Voltage of 48 Volts DC and an

      Input Voltage Range of 30-60 Volts DC

      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 1746-P6

      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC System
      • Spare Part Number:
        1746-P6/A
      • Estimated shipping dimensions:
        3x16.2x27.2cm
      • Weight:
        0.88 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Line Voltage:
        Line Voltage
      • Typical Line Power Requirement:
        100 VA
      • Maximum Inrush Current:
        20A
      • Internal Current Capacity:
        5A at 5V dc 0.96A at 24V dc
      • 24V dc User Power Current Capacity:
        200 mA
      • Isolation:
        1800V ac RMS for 1 s
      • CPU Hold-up Time:
        5 ms (full load) 1500 ms (no load)
      • Stock:
        30
      Ask for Quote

      Manuals

      1746-P6.pdf

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • What input voltage range and power characteristics does the 1746-P6 accept for proper operation within industrial control environments?
        The 1746-P6 operates within a 30 – 60 V DC input range, accommodating a broad DC supply envelope commonly used in industrial automation power networks. Its typical line power requirement is approximately 100 VA, providing sufficient capacity for driving backplane loads.
      • What are the ambient operating conditions under which the 1746-P6 will function reliably?
        The 1746-P6 is rated for operation in environments ranging from 0 °C to 60 °C (32 °F to 140 °F). Such a broad thermal tolerance allows it to be deployed in typical manufacturing, processing, and plant-floor conditions without derating below recommended thresholds.
      • How does the 1746-P6 handle brief power interruptions in SLC 500 systems?
        The design of the 1746-P6 supports brief hold-up times that allow the PLC backplane to maintain logic and I/O state during short power fluctuations or transient dropouts, which aids in preventing unintentional resets and improving system resilience.
      • How does the 1746-P6 compare with other SLC 500 power supplies such as the 1746-P5 or 1746-P7 in terms of input domain?
        Unlike the 1746-P5 (90-146 V DC input) and 1746-P7 (10-30 V DC isolated input), the 1746-P6 specifically targets a 30-60 V DC input domain, offering a mid-range DC supply option well-suited to installations with 48 V DC power infrastructures.
