      In Stock
      3300 XL 8 mm Proximity Probes

      330104-00-06-50-02-00

      Spare Part Number

      PN330104-00-06-50-02-00

      Product Information:

      3300 XL 8 mm Proximity Probes,

      330104 3300 XL 8 mm Probe, M10 x 1 thread,

      with armor

      3300 XL 8 mm Proximity Transducer System

      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs
      Technical specifications for

      330104-00-06-50-02-00

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        Bently Nevada
      • Product Category:
        Sensor
      • Spare Part Number:
        330104-00-06-50-02-00
      • Estimated shipping dimensions:
        12.5 x 20 x 13.6 cm
      • Weight:
        0.1 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Unthreaded Length:
        0 mm
      • Overall Case Length:
        60 mm
      • Total Length:
        5.0 meters (16.4 feet)
      • Connector and Cable-Type:
        Miniature coaxial ClickLoc connector, standard cable
      • Agency Approval:
        Not required
      • Series:
        3300 System
      • Stock Availability:
        30
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      3301040006500200 330104 00 06 50 02 00

      Manuals

      PRODUCT & ORDER FAQS

      Questions buyers ask about 330104-00-06-50-02-00

      • What specific functional role does 330104-00-06-50-02-00 fulfill within the Bently Nevada 3300 XL 8 mm Proximity Transducer System?

        The 330104-00-06-50-02-00 is an 8 mm proximity probe engineered to deliver high-resolution, non-contact measurement of shaft vibration, axial position, and radial displacement. As an integral sensing element within the 3300 XL system, 330104-00-06-50-02-00 enables precise condition monitoring of critical rotating machinery.

      • How does the eddy-current sensing technology employed by 330104-00-06-50-02-00 enhance measurement accuracy?

        The 330104-00-06-50-02-00 utilizes eddy-current transduction, generating a high-frequency electromagnetic field that interacts with conductive targets. Variations in target distance modulate the field impedance, allowing sub-micron resolution without physical contact, even at high rotational speeds.

      • What probe tip geometry and mechanical construction characterize 330104-00-06-50-02-00?

        The 330104-00-06-50-02-00 features a nominal 8 mm probe tip diameter housed in a corrosion-resistant stainless-steel body. This standardized form factor ensures compatibility with Bently Nevada probe holders and stable mechanical coupling in demanding industrial environments.

      • What linear measurement range is supported by 330104-00-06-50-02-00 when paired with a compatible 3300 XL Proximitor® sensor?

        When correctly matched with a 3300 XL Proximitor® sensor and appropriate extension cable, 330104-00-06-50-02-00 provides a linear measurement range of approximately 2.0 mm (80 mils), enabling accurate monitoring of dynamic vibration and static shaft displacement.

      • Which target material specifications are required to maintain calibration accuracy with 330104-00-06-50-02-00?

        The 330104-00-06-50-02-00 is factory calibrated for AISI 4140 steel targets. Deviations in target material composition, surface hardness, or finish may alter scale factor and linearity, necessitating careful material consideration in precision applications.

      • In what way does 330104-00-06-50-02-00 support predictive maintenance and machinery protection strategies?

        By delivering stable, repeatable displacement signals, 330104-00-06-50-02-00 enables early identification of mechanical anomalies such as shaft misalignment, bearing wear, and rotor instability. This data underpins predictive maintenance programs and reduces the likelihood of unplanned outages.

      • What electrical interface requirements must be observed when integrating 330104-00-06-50-02-00 into a monitoring system?

        The 330104-00-06-50-02-00 interfaces with compatible 3300 XL Proximitor® sensors via matched coaxial connections. Total electrical length—including probe cable and extension cable—must conform to system specifications to preserve calibration and ensure correct scale factor output.
