Features:
- Reverse-mount sleeved construction supports applications where the probe is retained from the rear of the mounting assembly.
- The fixed 0.2 in unthreaded and 1.2 in case dimensions define the mechanical fit of the 330105 execution.
- A one-metre standard cable and ClickLoc connector complete the documented probe-side connection to the extension cable.
The complete 330105-02-12-10-02-00 code must be retained because its mounting direction, thread, case geometry, lead length and connector option jointly determine installation fit.
Published scale factor, range and frequency response apply to a correctly matched 3300 XL 8 mm system using the specified target and test conditions. Probe replacement therefore requires checks of target material, gap and every connected component.
The exact item is supplied only after its complete label, condition and current OEM availability have been confirmed.
Bently Nevada 330105-02-12-10-02-00 Reverse-Mount Proximity Probe Manual(Datasheets), Link
Important Notice: The uploaded PDF documents the listed model or its identified manufacturer family. Confirm the complete order code, connected hardware and installation requirements before replacement. Accessories and cables are included only when stated in the quotation. All prices are shown in USD.
Confirm rear access, 3/8-24 UNF engagement and the fixed 0.2 in by 1.2 in sleeve geometry before removal.
Match the 1.0 m probe to the extension cable and Proximitor Sensor required for the installed total system length.
Set the probe against the approved target, verify bias near the documented gap point and compare slow-roll behavior with the baseline.
