      Bently Nevada 330130-045-03-05
      Bently Nevada 330130-045-03-05
      Bently Nevada 330130-045-03-05
      Bently Nevada 330130-045-03-05
      Bently Nevada 330130-045-03-05
      Bently Nevada 330130-045-03-05

      • ISO 9001:2015 Certified

        Our quality management system covers sourcing,testing and dispatch

      • View Our Success Stories

        Real stories from real customer orders
      In Stock
      Ships by Friday, November 6
      Fast Shipping Available
      3300 XL Standard Extension Cable

      330130-045-03-05

      Product Information:

      The 330130-045-03-05 is a 3300 XL 8mm standard extension cable designed for the condition monitoring of industrial rotating machinery. As a critical component of a high-precision eddy current transducer system, it reliably transmits raw electrical signals from the eddy current probe to the Proximitor sensor for linear signal conversion.

      Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote
      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs
        • PRODUCT OVERVIEW

          What is this product?

          The Bently Nevada 330130-045-03-05 is a 3300 XL 8 mm standard extension cable designed for use as a component of the 3300 XL 8 mm proximity transducer system. According to the manufacturer's official datasheet, the 3300 XL system comprises an 8 mm proximity probe, an XL extension cable, and a Proximitor sensor; the system outputs a voltage proportional to the distance between the probe tip and the conductive target, enabling the measurement of both static position and dynamic vibration.

          Source boundary

          Exact-model hardware values shown here are qualified from public technical cross-references and require order-stage confirmation.
        • APPLICATIONS

          Where it may be used

          Applications describe the product family and are not an automatic compatibility or functional-safety approval.

          Heavy Machinery

          Used with compatible proximity probes and Proximitor Sensors for monitoring vibration, position, Keyphasor reference, and speed on rotating equipment.

          Petrochemical

          Supports condition-monitoring installations on process machinery using the 3300 XL eddy-current proximity transducer system.

          Oil & Gas

          Used in proximity monitoring systems for vibration and shaft-position measurement on critical fluid-film bearing machinery.

          Power Generation

          Applied to rotating machinery monitoring systems where non-contact measurement of shaft vibration and position is required.
      Technical specifications for

      330130-045-03-05

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        Bently Nevada
      • Product Category:
        Cable
      • Cable Length:
        4.5 meters (14.8 feet)
      • Connector Protector and Cable:
        Armored cable with connector protector
      • Agency Approval:
        CSA, ATEX, IECEx Approvals
      • Series:
        3300 System
      • DC Resistance:
        0.99 ± 0.15 Ω
      • Resistance (RJACKET ) from Outer Conductor to Outer Conductor:
        0.30 ± 0.06 Ω
      • Capacitance:
        69.9 pF/m (21.3 pF/ft) typical
      • Stock Availability:
        2
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      3301300450305 330130 045 03 05 Bently Nevada 330130-045-03-05 330130-045-03-05 3300 XL Standard Extension Cable

      Information

      Overview Manuals Cable Construction Installation Note Approval Consideration

      Features:

      • Provides a 4.5 m (14.8 ft) extension length for the 3300 XL proximity transducer system.
      • Uses FEP/PFA-insulated triaxial cable with protective armor for demanding machinery-monitoring installations.
      • Forms part of the complete 3300 XL 8 mm system and supports interchangeability among compatible probes, extension cables, and Proximitor Sensors.

      The Bently Nevada 330130-045-03-05 is a 3300 XL standard extension cable designed for use with the 3300 XL 8 mm proximity transducer system. This system comprises a 3300 XL 8 mm proximity probe, a 3300 XL extension cable, and a 3300 XL Proximitor sensor. These components work together to provide non-contact measurement of shaft position and dynamic vibration in rotating machinery.

      In this configuration, the "-045" option specifies a cable length of 4.5 meters (14.8 feet). OEM data sheets indicate that the Model 330130 cable utilizes a triaxial cable construction with FEP or PFA insulation, featuring miniature coaxial connectors and stainless steel collars; the cable assembly is also available with connector protectors. The manufacturer specifies a maximum armor outer diameter of 7.67 mm (0.302 inches) and a maximum collar diameter of 10.2 mm (0.40 inches).

      The 330130-045-03-05 Bently Nevada Extension Cable may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Bently Nevada 330130-045-03-05 Extension Cable Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      The 330130 series uses a 75 Ω triaxial cable, with a maximum cable outside diameter of 3.7 mm, maximum armored diameter of 7.67 mm, and stainless-steel ferrules with a maximum diameter of 10.2 mm.
      When installing this extension cable, the connector and cable routing should be protected from mechanical damage, and the complete probe–extension cable–Proximitor Sensor combination should follow the manufacturer's specified system configuration.
      The extension-cable ordering structure includes an agency-approval option, and Bently Nevada notes that all components of a system installed in a hazardous area must have the required approvals. Therefore, the complete 330130-045-03-05 configuration should be verified against the site's hazardous-area certification requirements before installation.

      Technical notes

      This model features a 75Ω triaxial, low-loss construction; the "-045" suffix indicates a factory-calibrated electrical length of 4.5 meters (14.8 feet), while the "-03" designation signifies the inclusion of rugged stainless steel armor and connector protectors, significantly enhancing resistance to mechanical tension, abrasion, moisture, and contaminants in field applications. Additionally, the "-05" suffix indicates compliance with international hazardous area safety certifications, such as CSA, ATEX, and IECEx.

      Cable Configuration

      The 330130-045-03-05 is a 3300 XL Extension Cable with a 4.5 m (14.8 ft) cable-length option, using FEP/PFA-insulated triaxial cable and stainless-steel armor; the manufacturer specifies a maximum armor diameter of 7.67 mm (0.302 in) and a maximum ferrule diameter of 10.2 mm (0.40 in).

      Connection Design

      The 3300 XL extension cable uses miniature coaxial connectors and is designed as part of the complete 3300 XL 8 mm proximity transducer system, with the cable length selected to match the required probe and Proximitor Sensor system configuration.

      Customs & shipping dimensions / weight

      • Packed shipping dimensions
        Confirmed after final packing
        Bently Nevada product dimensions: 260 × 260 × 30 mm.
      • Packed shipping weight
        Confirmed after final packing
        Bently Nevada product net weight: 0.44 kg.
      • HS / customs code
        Not officially confirmed
        Verify the applicable classification for the destination before shipment.
      • Country of origin
        USA
        Verify from the item nameplate or COO.
      • Ships from
        Xiamen, Fujian, China
        Dispatch location is confirmed in the written quotation.
      • Customs documents
        Confirmed for the destination
        Available document scope is stated in the written quotation.
      PRODUCT & ORDER FAQS

      Questions buyers ask about 330130-045-03-05

      • How do I determine the specific configuration of the 330130-045-03-05?

        This model number represents a 3300 XL standard extension cable. Its configuration includes: "-045" for the 4.5-meter (14.8-foot) length option; "-03" for an armored cable with connector protectors; and "-05" for a multiple-approval configuration. When replacing an existing cable, it is recommended to verify the full model number rather than selecting based on length alone, as the protection method and approval configuration are also critical components of the specified assembly.

      • Can this 4.5-meter cable be used with my existing 3300 XL proximity measurement system?

        Yes. This cable is designed specifically for the 3300 XL proximity transducer system; however, you should verify the complete system configuration before ordering. Bently Nevada defines the 3300 XL system as a matched set of components—probe, extension cable, and Proximitor sensor—that are interchangeable within applicable system configurations.

      • What is the purpose of the armored construction and connector protectors on this version?

        The "-03" configuration features an armored cable with connector protectors, making it suitable for installations where the cable routing requires additional mechanical and environmental protection at the connection points. This is particularly important in machinery installations where cables may be exposed to vibration, oil, moisture, or the risk of physical contact.

      • Where is the 330130-045-03-05 typically installed?

        It is used for machinery condition monitoring as part of the 3300 XL eddy-current proximity measurement system. In this system, the probe detects the position or vibration of a conductive target, while the extension cable transmits the signal between the probe and the Proximitor sensor. Bently Nevada identifies vibration and position measurements on fluid-film bearing machinery, as well as Keyphasor and speed measurements, as primary applications for the 3300 XL proximity system.

      • Does the 4.5-meter length need to match the other components of my transducer system?

        Yes. The 4.5-meter (14.8-foot) cable length is part of a specific configuration; therefore, when selecting components, you should choose the probe and Proximitor sensor based on the required total system length, rather than treating the extension cable as a standalone, universal item. If you can provide the model numbers of your existing probe and Proximitor sensor, we can assist in verifying the configuration before you place your order.

      • Is there a brand-new, original replacement available for model 330130-045-03-05?

        We supply brand-new, original Bently Nevada products backed by a one-year warranty. Stock availability depends on current warehouse inventory; before you place an order, we can confirm the current stock level, product condition, packaging details, and estimated shipping time for this model (330130-045-03-05).

      • Can you provide certificates, technical documentation, or actual photos of the product before shipment?

        Yes. We can provide relevant technical data, actual product photos, and applicable certificates to help you verify your order. Depending on the product and accompanying documentation, certificates may include a Certificate of Origin (COO), Certificate of Conformance (COC), test reports, calibration records, or warranty letters. If you require specific certificates, please let us know before placing your order so we can verify availability in advance.

      • Can you arrange shipping and offer a better price for the 330130-045-03-05?

        Yes, we can arrange door-to-door delivery via DHL or FedEx; the final shipping cost depends on the destination and specific shipment details. If you have a target purchase price in mind, please let us know so we can request a special discount for you; this approach is often more efficient than simply applying a standard discount without knowing your budget.
