Features:
- Exact 135826-01 male-to-male sensor mounting stud.
- 1/4-28 UNF male thread at the sensor side.
- M10 x 1.0 male thread at the machine mounting side.
The 135826-01 standard stud converts a 1/4-28 UNF male sensor mounting interface to an M10 x 1.0 male machine-side interface. Bently Nevada lists it in the 177230 Seismic Transmitter ordering accessories, so it must be treated as a mechanical mounting part rather than a sensor, cable or signal-conditioning device.
Before installation, confirm both mating thread standards, usable thread depth, mounting-face flatness, cleanliness and final sensor orientation. Do not infer compatibility solely from thread engagement; follow the receiving sensor installation instructions and apply the specified torque for that sensor and mounting arrangement.
The 135826-01 Bently Nevada M-M 1/4-28 UNF to M10 x 1.0 Standard Stud may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 135826-01 documentation and reference links.
Important Notice: The official 177230 datasheet identifies 135826-01 as a mounting stud accessory. Confirm the complete part number, supplied marking, receiving hardware and required accessories before replacement.
The 135826-01 stud has a 1/4-28 UNF male sensor-side thread and an M10 x 1.0 male machine-side thread. It is a mechanical adapter only and does not alter, condition or transmit the sensor electrical signal.
Inspect both mating threads, confirm usable engagement depth and clean the mounting face before assembly. Follow the receiving sensor instructions for final torque and orientation; cross-threading or an uneven surface can compromise measurement quality.
The official 177230 datasheet lists 135826-01 among its mounting accessories. Do not extend that compatibility to another sensor solely because the thread appears to fit; confirm the exact sensor manual and machine-side interface first.
