Features:
- F 8652X Central module
- Central module with two clock-synchronized microprocessors
- Use in the PES H41q-MS, -HS, -HRS, Safety-related, applicable up to SIL 3 according to IEC 61508
The F8652X is a high-integrity safety system controller manufactured by HIMA. It is the "brain" of HIMA's H41q and H51q programmable electronic safety (PES) systems, which are critical for monitoring and controlling industrial processes where failures can lead to catastrophic events.
For serial interfaces, only bus station numbers 1 to 31 can be set. In Ethernet, bus station numbers can be set from 1 to 99. Therefore, in addition to switches S1-1/2/3/4/5, switches S1-6/7 must also be set. The number of communication partners in the network remains limited to 64. This enhanced bus station numbering feature is only available for the central module's operating system BS41q/51q V7.0-8 (05.31).
The F8652X HIMA Central module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
HIMA F8652X Central module manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The F8652X primarily operates based on secure communication processing and redundant network management mechanisms. As a communication processor in a safety control system, this module first receives data frames from safety controllers, engineering stations, or monitoring systems via its industrial communication interface. Subsequently, its internal dedicated processor performs protocol parsing, integrity verification, and time consistency verification on the data to ensure that the information meets functional safety communication requirements.
Applications using the F 8627X communication module:
– Connecting the central module to PADT (ELOP II TCP)
– Connecting to other communication partners on Ethernet (safeethernet, Modbus TCP)
Communication runs from the central module to the F 8627X communication module via the backplane bus, and from the F 8627X's Ethernet port to the Ethernet, and vice versa.
