Features:
- Honeywell identifies a coated nine-inch non-redundant analog-input IOTA.
- The manufacturer pairs it with 8C-PAIH54 high-level HART electronics.
- 8C-TAIDB1 is the distinct redundant twelve-inch IOTA.
The March 2022 Honeywell Series 8 Controller and I/O Specification names 8C-TAIDA1 in its hardware summary, detailed high-level AI HART table and function matrix. It is the coated, non-redundant, nine-inch IOTA paired with the 8C-PAIH54 electronic IOM. That module supports high-level analog-input channels and single-ended or differential connections under the documented system design. The same table separates 8C-TAIDB1 as a larger redundant termination. The architecture and physical dimensions matter when selecting a spare, and similar model prefixes do not establish interchangeability.
The IOTA provides field termination and a physical interface to the separate I/O electronics. Honeywell's A/D converter, HART, input-range and filtering details describe the electronic IOM and complete signal path, not standalone processing performed by the termination board. Before replacement, identify the installed cabinet generation, IOM, input topology, power and wiring, revision and complete physical markings. The official PDF establishes 8C-TAIDA1 identity but does not validate extra website number 51307131-175; verify it from a supplied label or Honeywell parts record. Follow approved isolation and manufacturer procedures, then prove affected inputs after installation.
The 8C-TAIDA1 51307131-175 Honeywell Series 8 Non-Redundant HART AI IOTA may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 8C-TAIDA1 51307131-175 official technical documentation and product links.
This multi-page Honeywell technical document contains the exact model and its technical data. Apply the values to the supplied type number and verify its revision before installation.
Honeywell lists 8C-TAIDA1 as a coated nine-inch non-redundant analog-input IOTA. Its paired 8C-PAIH54 electronic module provides high-level HART input processing. The manufacturer names 8C-TAIDB1 separately for redundant termination. Match the physical length, cabinet mounting, IOM and installed field wiring before ordering; the two assemblies are not automatically interchangeable.
The detailed Honeywell table gives 8C-PAIH54 input-channel and signal specifications alongside its IOTA choices. A/D resolution, ranges and HART behavior belong to the electronic IOM and complete loop, not independent functions of 8C-TAIDA1. Confirm whether the installed design uses single-ended or differential inputs and how field power is supplied before applying the table.
The direct Honeywell PDF prints exact 8C-TAIDA1 and its non-redundant IOTA role but does not map website number 51307131-175. Check the full part and revision on the supplied physical item or an OEM parts record. Current release and cabinet compatibility must still be verified against the plant installation before using it as a spare.
