Features:
- Exact Honeywell model entry identifies eight analog output points.
- The TK execution is coated and described as non-isolated.
- Exact output range and load remain unspecified in the reviewed list.
Honeywell's November 2020 System HINTS model table explicitly calls TK-OAV081 an 'Analog Output, 8 pt (non-isolated), coated' module. This supports eight output points, non-isolated arrangement and coated execution. It does not itself identify a specific current or voltage range or allowable load. A neighboring TC-OAV081 row mentions 4–20 mA and 10 V, but the prefixes and entries differ; those values should not be presented as proven TK-OAV081 specifications. Obtain a matching manufacturer technical sheet or Honeywell parts confirmation before engineering a new field circuit or approving a replacement as electrically interchangeable.
For an installed system, capture the complete TK-OAV081 label, hardware revision, chassis position, eight point assignments, output scaling, connected loads, common and grounding design, and baseline actuator positions. Follow site change control, isolation and ESD handling instructions. Non-isolated output arrangements require careful verification of shared references and field wiring before energizing. After an approved change, confirm each channel's commanded and measured output, actuator response, alarms and failure behavior using a safe commissioning procedure. The cited HINTS list is an identity source, not a complete performance or safety certificate.
The TK-OAV081 Honeywell Coated 8-Point Non-Isolated Analog Output Module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell TK-OAV081 official technical documentation and product links.
This multi-page Honeywell technical document contains the exact model and its technical data. Apply the values to the supplied type number and verify its revision before installation.
Honeywell's TK-OAV081 row describes a coated, eight-point, non-isolated analog-output module. Preserve that exact designation and do not replace it with the neighboring TC-OAV081 or TK-OAV061. The model list confirms point count and general construction but is not a full output-circuit specification. Compare the physical unit and system drawing before procurement, especially when similar modules occupy the same cabinet.
The reviewed exact-model row does not publish output current or voltage range, load capability, resolution, accuracy or channel fault behavior. Values stated for the adjacent TC-OAV081 cannot be automatically applied to the TK coated execution. Non-isolated outputs make grounding and shared-common checks important, but the list does not prescribe a wiring method. Obtain an exact Honeywell data sheet or qualified manufacturer confirmation before assigning electrical limits or claiming interchangeability.
Record baseline output commands, measured loop values, actuator positions, alarms, eight channel assignments and shared reference wiring before a controlled replacement. Verify the supplied coated model and physical revision, then follow plant isolation and change-control requirements. Restore approved configuration and test each affected analog output with suitable process safeguards. Do not assume the module can safely drive a specific actuator or load solely from its eight-point description.
