Features:
- Modicon M340 processor CPU module
- Max 1024 discrete, 256 analog IO, CANopen, Ethernet
- Ethernet TCP/IP RJ45, transmission mode: 1 twisted pair at 10/100 Mbit/s
This processor module is part of the Modicon M340 series of programmable automation controllers (PACs). It supports up to four-rack configurations, providing 36 application-specific channels, 63 CANopen slaves, and 11 slots. The module consumes 135mA at 24V DC and is powered by an internal power supply.
It is rugged, high-quality, and based on the latest innovative technology. The communication processor module interfaces include two Ethernet modules and four AS-Interface modules. It comes with a memory card for backing up programs, constants, symbols, and data. The product has an IP20 protection rating. The module provides 1024 discrete I/O processors in a multi-rack configuration and 704 discrete I/O processors in a single-rack configuration; additionally, it provides 256 analog I/O processors in a multi-rack configuration and 66 analog I/O processors in a single-rack configuration.
The BMXP3420302 Schneider Electric CPU processor module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Schneider Electric BMXP3420302 CPU processor module Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
This processor module is compatible with the Modicon M340 programmable logic controller (PLC). It features a memory card (BMXRMS008MP) for backing up programs, constants, symbols, and data; 4096kB of internal RAM; 256kB of internal RAM for data storage; and 3584kB of internal RAM for storing program constants and symbols. The Modicon M340 boasts a compact design, integrating flexibility and functionality into a small chassis. As the core of the process, it offers plug-and-play compatibility with Schneider Electric and third-party devices.
This processor is widely used in industries requiring high reliability and flexible communication:
Process Industries: Used in water treatment, cement production, and chemical processing, managing up to 1024 discrete I/O points and 256 analog I/O points in multi-rack configurations.
Infrastructure and Utilities: Due to its robust environmental protection rating and remote monitoring capabilities via Ethernet, this processor is commonly used in renewable energy (solar/wind) and water resource management.
Machine Control: Its integrated CANopen master port makes it ideal for motion control and independent axis management in manufacturing and packaging machinery.
Industrial IoT and Remote Monitoring: Can be used as a data gateway with a built-in web server (B10 class), allowing technicians to view rack status and diagnostic information via a standard web browser.
