      1756-IF16K

      Analog Input Module
      In Stock

      Product Information:

      ControlLogix Analog Input

      Module with 16 single, 8

      differential, 4 highspeed

      differential Inputs

      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 1756-IF16K

      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC System
      • Estimated shipping dimensions:
        3.5x14.2x14.5cm
      • Weight:
        0.22 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Inputs:
        16 single, 8 differential, 4 highspeed differential
      • Input Resolution:
        (+--)10.25 Volts, 0-5.125 Volts, 0-10.25 Volts
      • Backplane Current (5Volts):
        150 milliamps
      • Power Dissipation (Max):
        2.3 Watts (Voltage), 3.9 Watts (Current)
      • Maximum Input Current, Off-State:
        1.5 milliamperes
      • Stock:
        30
      Ask for Quote

      Manuals

      1756-IF16K.pdf

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • How many input channels does the 1756-IF16K support and what configurations are available?
        The 1756-IF16K supports 16 single-ended inputs, or can be configured for 8 differential inputs, or 4 high-speed differential inputs, providing flexibility in signal wiring and measurement topology based on application requirements.
      • What level of measurement resolution and accuracy does the 1756-IF16K provide?
        The 1756-IF16K delivers high precision with a resolution of 320 µV/count in ±10.25 V range and up to 0.32 µA/count in 0–20.5 mA mode (using 16-bit conversion), enabling fine-grained analog signal discrimination suitable for demanding control loops.
      • What input impedance and sampling performance does the 1756-IF16K exhibit?
        The 1756-IF16K features high input impedance for voltage mode (>10 MΩ) and approximately 249 Ω for current mode, ensuring minimal loading on connected sensors. Channel update times vary with configuration but provide responsive sampling for multi-channel analog acquisition.
      • Does the 1756-IF16K module include conformal coating or environmental protection features?
        The 1756-IF16K often includes a conformal coating variant that enhances its resilience to humidity, dust, and corrosive environments on the factory floor, improving long-term reliability in challenging industrial conditions.
      • How does the 1756-IF16K module integrate with Rockwell’s Logix environment for configuration and diagnostics?
        The 1756-IF16K integrates seamlessly with Studio 5000 Logix Designer®, allowing engineers to configure analog scaling, alarm conditions, and channel-specific parameters. The module also supports real-time diagnostics and status feedback via the controller’s I/O tag structure.
