      1756-IR12

      ControlLogix analog input module

      Product Information

      Product Describe

      ControlLogix analog input module

      features 12 channels in the 3-wire

      RTD mode and it is used as a

      general-purpose I/O device

      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC System
      • Spare Part Number:
        1756IR12
      • Estimated shipping dimensions:
        3.5x14x14.5cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Number of channels:
        12, non-isolated
      • Data resolution:
        24-bit
      • Mounting:
        Chassis
      • Display:
        Status LED
      • Input/output range:
        1 to 500/2 to 1000/4 to 2000/8 to 4000 Ohms
      • Isolation voltage:
        250 Volts (continuous)
      • Current draw at 5.1 Volts DC:
        200 milli Amps
      • Operating temperature:
        0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
      • Stock:
        20
      By purchasing this item, you agree to the Terms & Conditions
      Moore Automated is NOT an authorized distributor of Allen-Bradley
      right background
      1-year warranty

      All our products come with a 1-year warranty for your peace of mind.

      Service means taking a customer problem and making it your own challenge. Years of experience and listening skills enable us to think and act quickly and accordingly. You have a problem? – We have the solution!
      Moore Automated is not an authorized distributor, reseller or representative of the products featured on this website.
      All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
      Learn More Policy
      Manuals
      1756-IR12.pdf
      • Order Online:
        We have been working hard to update our inventory.

        If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show “Ask”. Please create an online quote or contact us by phone, fax or email to check availability.
      • Order by:
        You can also contact us by phone, fax or email to order. We are here to help you!
      • E-mail:
        We need the following information to process your order quickly and accurately: Your complete ship and receipt information
      • Delivery:
        How do you want to ship? Shipping information
      • Payment:
        How will you pay? Payment procedure
      Learn More Policy
      Quantity*
      Mobile*
      Company
      E-mail*
      Content*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote

      Quick Search

      • Part or Model Number

        • Please try to be as accurate as possible with your search.
        • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
        • We can't find any results for “”.
          SEE MORE
            SEE PRODUCTS IN SEARCH PAGE ()

          • Filter by Manufacturer

          • Filter by Category

          Featured Manufacturers

          FAQ

          • What is the defined functional role of the 1756-IR12 within the Allen-Bradley ControlLogix modular I/O architecture?
            The 1756-IR12 is a ControlLogix RTD (Resistance Temperature Detector) analog input module designed to acquire multi-channel resistance measurements—typically from 3-wire RTD sensors—and convert them to high-resolution digital values that the controller can process for precision temperature control and monitoring.
          • How does the 1756-IR12 deliver high-fidelity sensing for industrial temperature measurement applications?
            The 1756-IR12 incorporates 24-bit resolution conversion, enabling fine-granularity data acquisition and precise interpretation of small resistance changes from RTD sensors across its 12 individual input channels, which enhances temperature control accuracy in closed-loop systems.
          • What RTD sensor ranges and resistance spans are supported by the 1756-IR12?
            The 1756-IR12 supports a range of resistance spans from 1…500 Ω through 8…4000 Ω, allowing compatibility with a wide variety of platinum, nickel, and copper RTD sensor types used in diverse industrial environments.
          • What key diagnostic and signal integrity-enhancing features does the 1756-IR12 include?
            The 1756-IR12 module integrates notch filtering, digital filtering, wire-off detection, sensor offset compensation, and automatic last-used range recall—all of which improve signal quality, enhance measurement stability, and reduce the need for frequent reconfiguration during maintenance.
          • What are the electrical and thermal specifications associated with the 1756-IR12 module?
            The 1756-IR12 draws approximately 200 mA at 5.1 V DC and 70–150 mA at 24 V DC from the backplane, with a maximum power dissipation of 2.7 W and corresponding thermal dissipation around 9.2 BTU/hr, which must be considered when planning power and thermal budgets for the chassis.
