Features:
- Honeywell's supported-module table identifies FC-PUIO01 as Universal Safety I/O.
- The reviewed table pairs FC-PUIO01 with a TUIO11 IOTA and SIC system cable.
- Honeywell's cable section describes the FC-SIC5xxx family and 37-position D-sub IOTA connection.
The reviewed Honeywell Release 310 specification concerns the Universal Marshalling Solution for Safety Systems. Its supported-module tables list FC-PUIO01 as Universal Safety I/O with a TUIO11 IOTA and SIC cable. The SIC cable section specifically names FC-PUIO01 and describes how the system cable connects the Safety Manager SC I/O module to an SCA through an IOTA. It identifies a 37-position D-sub connector and the CN1 and CN2 positions on that termination arrangement. These are connection-context facts, not a general module electrical datasheet.
Before ordering or replacing FC-PUIO01, compare the full physical marking, additional 51454294-176 number, revision and system bill of materials. Confirm the installed IOTA, cable, SCA, controller release and approved application design from the complete Honeywell safety-system documentation. Qualified personnel should follow the site's safety lifecycle, isolation and change-control processes before disturbing a safety loop. After the exact approved hardware is installed, verify module recognition, channel configuration, diagnostics and affected safety functions using the approved commissioning and proof-test procedures.
The FC-PUIO01 51454294-176 Honeywell Universal Safety I/O Module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell FC-PUIO01 51454294-176 documentation and reference links.
The link opens Honeywell's original Release 310 document at the manufacturer site; the PDF is not copied or re-hosted here. Its FC-PUIO01 entries are in supported-module tables and the SIC cable section, not a dedicated module datasheet. Do not apply adjacent SCA ratings to this module.
Honeywell's supported-module list names FC-PUIO01 and describes it as Universal Safety I/O. The reviewed pages do not state that the site's additional 51454294-176 number is the corresponding manufacturer order number. Inspect the supplied unit's full label and verify the procurement identity and revision against Honeywell records and the site's approved bill of materials.
The 2021 Honeywell specification pairs FC-PUIO01 with a TUIO11 IOTA and SIC cable. Its cable section says FC-SIC5xxx connects Safety Manager SC I/O modules to an SCA through an IOTA and describes the 37-position D-sub connection. Verify the exact termination assembly, cable length, connector position and approved wiring drawings for the installed system before service.
The reviewed pages do not supply a complete FC-PUIO01 channel specification, safety certification statement or electrical rating. Nearby tables describe SCA devices and must not be transferred to the I/O module. Use the applicable Honeywell module manual, approved safety design and site proof-test procedure to confirm configuration and demonstrate correct operation after replacement.
