Features:
- 9-inch 800 x 480 TFT display
- 26 LED function keys
- PROFINET and MPI/PROFIBUS DP
Product Overview
6AV2124-1JC01-0AX0 is a Siemens SIMATIC HMI KP900 Comfort Panel with key operation and a 9-inch widescreen TFT display. The display supports 16,777,216 colors at 800 x 480 pixels.
The panel provides 26 LED function keys, PROFINET and MPI/PROFIBUS DP interfaces, and 12 MB configuration memory. It runs Windows CE 6.0 and is configurable from WinCC Comfort V11.
Siemens lists the product in phase-out and identifies 6AV2128-3KB06-0AX1 as the successor. Installation dimensions and project migration must be checked before replacement.
Technical Configuration
- Product Type: KP900 Comfort
- Display: 9-inch widescreen TFT
- Resolution: 800 x 480 pixels
- Colors: 16,777,216
- Function Keys: 26 with LEDs
- Configuration Memory: 12 MB
- Interfaces: PROFINET and MPI/PROFIBUS DP
- Operating System: Windows CE 6.0
Application Context
It is used for machine visualization, alarm handling, operator commands and process monitoring where physical function keys are required.
It is compatible with projects engineered in WinCC Comfort V11 or higher and automation networks using PROFINET or MPI/PROFIBUS DP.
The 6AV2124-1JC01-0AX0 Siemens product is listed as Active/Available from OEM. Moore Automated supports order-code verification, replacement planning and spare-parts supply to help reduce maintenance risk and plant downtime.
Siemens 6AV2124-1JC01-0AX0 Official PDF and Product Support
The first link opens the matched PDF directly in a new browser tab. The remaining links stay within Moore Automated.
Important Notice: Accessories, software, cables, licenses and calibration records are supplied only when specifically stated in the quotation or stock description.
The 9-inch widescreen TFT displays 16.7 million colors at 800 x 480 pixels. Twenty-six LED function keys support direct operator commands and status indication.
Application Detail
It is used for machine visualization, alarm handling, operator commands and process monitoring where physical function keys are required.
It is compatible with projects engineered in WinCC Comfort V11 or higher and automation networks using PROFINET or MPI/PROFIBUS DP.
Key Parameters
- Product Type: KP900 Comfort
- Display: 9-inch widescreen TFT
- Resolution: 800 x 480 pixels
- Colors: 16,777,216
- Function Keys: 26 with LEDs
Siemens identifies 6AV2128-3KB06-0AX1 as the successor. Verify installation dimensions, WinCC project migration and communication settings before replacing the KP900.
Installation and Replacement Guidance
Verify the panel cutout, 24 V DC supply, PROFINET/PROFIBUS settings and WinCC project version. The successor has different installation dimensions.
The KP900 Comfort combines a 9-inch 800 x 480 TFT display, 26 LED function keys, 12 MB project memory and both PROFINET and MPI/PROFIBUS DP connectivity. Siemens identifies 6AV2128-3KB06-0AX1 as the successor, with installation dimensions requiring verification.
Before commissioning, verify the complete order number 6AV2124-1JC01-0AX0, physical interface, engineering software or firmware requirements, and the configuration of the existing Siemens system.
