      SIMATIC HMI OP17/DP operator panel

      6AV3617-1JC20-0AX1

      Spare Part Number

      PN6AV3617-1JC20-0AX1

      Product Information:

      Siemens 6AV3617-1JC20-0AX1 is a SIMATIC HMI OP17/DP operator panel with a backlit LC display that presents either four lines of 20 characters or eight lines of 40 characters.

      This DP version communicates with SIMATIC S7 and M7 systems through PPI, MPI or PROFIBUS-DP at up to 1.5 Mbaud. The OP17 hardware also provides two RS232 interfaces and one TTY interface for engineering, printer or controller communication.

      The panel operates from a nominal 24 V DC supply with an allowable 18 to 30 V DC range and uses internal buffering for message data and the hardware clock. Confirm the ProTool project, interface settings, network address, connector wiring and panel cutout before replacement.

      Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote
      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs

      Technical specifications for

      6AV3617-1JC20-0AX1

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        Siemens
      • Product Category:
        HMIs and Displays
      • Spare Part Number:
        6AV3617-1JC20-0AX1
      • Estimated shipping dimensions:
        28.70 x 25.00 x 8.00 cm
      • Weight:
        0.56 kg
      • Tariff Code:
        853710
      • Country of origin:
        Germany
      • Place of shipment:
        Xiamen, Fujian, China
      • Panel family:
        SIMATIC HMI OP17
      • Interface version:
        OP17/DP
      • Display:
        Backlit LC
      • Display format:
        4 x 20 or 8 x 40 characters
      • Rated supply:
        24 V DC
      • Supply range:
        18 to 30 V DC
      • Typical current:
        340 mA at 24 V
      • Maximum continuous current:
        390 mA at 24 V
      • RS232 interfaces:
        2
      • TTY interfaces:
        1
      • Fieldbus:
        PPI/MPI/PROFIBUS-DP up to 1.5 Mbaud
      • Configuration software:
        ProTool
      • Stock Availability:
        26
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      6AV3617-1JC20-0AX1 6AV3617-1JG30-0AX0

      Information

      Overview Manuals Operator Functions Interface Configuration Migration Guidance

      Features:

      • Text-based SIMATIC HMI operator panel
      • Backlit LC display with membrane-key operation
      • PPI, MPI and PROFIBUS-DP communication up to 1.5 Mbaud
      • Configured with SIMATIC ProTool

      The Siemens 6AV3617-1JC20-0AX1 is a SIMATIC HMI OP17/DP operator panel for local machine operation, message display and parameter entry. The panel combines a backlit text display, membrane keys and configurable function-key behavior for legacy automation systems.

      Serial and fieldbus interfaces provide connections to supported controllers and peripheral devices. Replacement requires verification of the complete order number, ProTool project, communication driver, bus settings, power supply, panel cutout and connector assignments.

      The Siemens 6AV3617-1JC20-0AX1 is obsolete; SIMATIC HMI TP700 Comfort 6AV2124-0GC01-0AX0 is an engineered modernization option that requires project conversion.
      Siemens 6AV3617-1JC20-0AX1 SIMATIC HMI OP17/DP Operator Panel Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

      Operator Functions:

      • Text and alarm display
      • Parameter and setpoint entry
      • Configurable function keys
      • Recipe and message handling depending on project

      Available functions depend on the ProTool configuration loaded in the panel and the connected controller program.

      Interface Configuration:

      • PPI communication
      • MPI communication
      • PROFIBUS-DP up to 1.5 Mbaud
      • Additional serial interfaces

      Record network address, baud rate, cable pinout and protocol driver before removing the original panel.

      Migration Guidance:

      • Archive the ProTool project
      • Export texts and alarm lists
      • Verify panel cutout and mounting
      • Convert communication and screen logic

      A modern touch panel is not a direct replacement; complete project conversion and machine validation are required before commissioning.

      Technical notes

      Siemens 6AV3617-1JC20-0AX1 is an OP17/DP text operator panel with a backlit character display, 24 V DC supply and SIMATIC S7/M7 fieldbus communication up to 1.5 Mbaud. Replacement requires the original ProTool project, correct interface parameters and matching panel wiring.
