Features:
- SB Bus Repeat Module for the documented Yokogawa STARDOM FCN.
- Bus Function: SB bus repeat.
- Controller Family: STARDOM FCN.
NFSB100-S01 belongs to the Yokogawa STARDOM FCN and performs the documented sb bus repeat module role in the Yokogawa STARDOM FCN autonomous controller. The retained technical evidence records Bus Function: SB bus repeat; Controller Family: STARDOM FCN; Module Format: DIN-rail communication module. The full marking, receiving hardware, connectors or terminals, configuration dependencies and installed position must be matched before substitution.
For installation, retain the Yokogawa STARDOM FCN receiving position, connector or terminal arrangement and configuration record. After power restoration, review diagnostics and test the affected operating path before process release.
The NFSB100-S01 SB Bus Repeat Module is supplied only after the complete hardware identity, condition and current OEM lifecycle status have been confirmed.
NFSB100-S01 Yokogawa product documentation and selection resources.
Important Notice: The PDF documents NFSB100-S01 or its verified Yokogawa product family. Confirm the complete suffix code and installed-system requirements before replacement.
Port Mapping: NFSB100-S01 performs the sb bus repeat module function within the Yokogawa STARDOM FCN. The retained documentation identifies bus function as SB bus repeat; apply that value only to this documented execution.
Match the complete label, hardware form and functional position before transferring any setting, cable or termination from the removed unit.
Module Matching: approve NFSB100-S01 only for the documented Yokogawa STARDOM FCN autonomous controller. Compare rack, carrier or panel generation, connector keying, terminal numbering and all paired assemblies with the installation drawings.
Photograph both sides and the installed position before removal so revision markings, jumpers, addressing and channel allocation can be reconstructed accurately.
Final Checks: isolate the equipment, remove stored energy and inspect the receiving hardware before installing NFSB100-S01.
Restore power in the approved sequence, review status and diagnostics, then test every affected control, signal, relay, communication, protection or monitoring path against the commissioning record.
