ABB IMDSM05 is a 16-channel digital i/o slave module in the Harmony Rack I/O family. It combines discrete input and output handling in one rack I/O module for 24 V DC control circuits. Its ordering identity should be checked exactly against the installed module before procurement.
ABB documentation identifies 16 configurable digital i/o points, 24 v dc field application, points arranged in groups of eight. Use the approved rack position, termination hardware, power arrangement, and system configuration specified for the application.
The ABB IMDSM05 is a legacy ABB module. Moore Automated can support replacement and spare-part requirements; the documented evolution reference is SPDSI22 and SPDSO14, or SD DI03 and DO01, subject to application verification.
ABB IMDSM05 16-Channel Digital I/O Slave Module Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Network Role
ABB IMDSM05 combines discrete input and output handling in one rack I/O module for 24 V DC control circuits. Official ABB documentation identifies 16 configurable digital i/o points, 24 v dc field application, points arranged in groups of eight.
Configuration Requirements
Match the complete IMDSM05 order identity with the installed ABB rack, backplane, termination unit, field signal, power supply, and engineering configuration. Commission the replacement only after wiring and channel assignments have been verified.
Migration Notes
Obsolete/Discontinued by OEM. The official evolution reference is SPDSI22 and SPDSO14, or SD DI03 and DO01; final selection requires application-specific verification. Moore Automated supplies high-quality ABB replacement modules and spare parts to help reduce customer downtime.
