      In Stock
      Terminal Block

      1769-RTBN18/A

      Spare Part Number

      PN1769-RTBN18/A

      Product Information:

      CompactLogix series is designed

      for multiple applications. This unit

      has 18 pins and accommodates a

      specific quantity of 1 per kit.

      • One-year warranty
      • Global shipping
      • Exact-model verification
      WhatsApp: +86 180 2077 6792 Email parts team
      01


      Model Verified

      Model, revision and nameplate reviewed
      02


      Email confirmation

      You will get an email confirming that we have received your enquiry
      03


      Dedicated Account Manager

      One of our team will be in touch to confirm your part(s) specification and condition
      04


      Your quote

      You will receive a comprehensive quote tailored to your specific needs
      Technical specifications for

      1769-RTBN18/A

      0 TECHNICAL PARAMETERS
      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC Systems
      • Spare Part Number:
        1769-RTBN18/A
      • Estimated shipping dimensions:
        12.5x3.5x14.5cm
      • Weight:
        0.34 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Product Type:
        Terminal Block
      • Product Line:
        CompactLogix
      • Pins:
        18 Pins
      • Wire Temperature Rating:
        90 °C
      • Solid Wire Size:
        22 to 14 AWG
      • Stranded Wire Size:
        22 to 16 AWG
      • Operating Temperature Rating:
        0 to 60 °C
      • Operating Humidity:
        80% max. (non-condensing)
      • Series:
        Allen-Bradley CompactLogix
      • Stock Availability:
        20
      Ask for Quote
      WHAT HAPPENS NEXT?

      From enquiry to delivery

      Six clear steps show what information is required and what the written quotation will contain.
      • 01

        Find the product

        Search the part number or send an inquiry for obsolete, discontinued or hard-to-find parts.
      • 02

        Provide the details

        Share the exact part number, quantity, condition, revision, destination and any required certificates or photos.
      • 03

        Review the quotation

        Receive price, currency, condition, availability, warranty, lead time, shipping terms and quotation validity in writing.
      • 04

        Confirm the order

        Accept the quotation in writing and complete the required payment before shipment.
      • 05

        Pay by bank transfer

        Pay the full invoiced amount by bank wire in RMB/CNY, GBP, EUR or USD using the official invoice details.
      • 06

        Verify and dispatch

        The item receives a pre-shipment inspection and suitable protective packaging. Functional testing is performed only where appropriate equipment and procedures are available for the specific item. We confirm the applicable inspection scope and provide tracking after dispatch.
      Request a Verified Quote
      BUYER INFORMATION

      Product condition level information

      Commercial details are confirmed in writing before payment.
      • 01

        Factory Sealed

        Unused product with the original factory seal intact; packaging age or storage marks may still be present.

        view
      • 02

        Original Pack

        Unused product in original manufacturer packaging that was not originally factory sealed.

        view
      • 03

        Factory New

        New and current product sourced through the manufacturer or authorized supply channel when expressly confirmed in the quotation.

        view

      Alternative Names

      1769RTBN18A 1769 RTBN18 A

      Manuals

      1769-RTBN18/A.pdf
      PRODUCT & ORDER FAQS

      Questions buyers ask about 1769-RTBN18/A

      • What is the functional purpose of the 1769-RTBN18/A in an Allen-Bradley CompactLogix 5370 automation system?

        The 1769-RTBN18/A is an 18-position removable terminal block designed for use with 1769 Compact I/O modules. It provides a convenient field-wiring interface between module terminals and external sensors/actuators, facilitating clean, organized, and robust wiring within CompactLogix installations.

      • How does the 1769-RTBN18/A enhance system maintainability and module replacement workflows?

        By acting as a removable wiring interface, the 1769-RTBN18/A allows field conductors to remain terminated when a Compact I/O module is removed. This greatly reduces downtime during maintenance and simplifies diagnostics by isolating wiring from module replacement.

      • What are the mechanical and environmental ratings associated with the 1769-RTBN18/A accessory?

        The 1769-RTBN18/A terminal block is rated for standard industrial ambient conditions with an operating temperature range from 0 °C to 60 °C (32 °F to 140 °F) and is designed for use in protected control cabinets. Its rugged NEMA-style construction ensures durability in industrial environments typical of CompactLogix deployments.

      • Can the 1769-RTBN18/A terminal block be used across different I/O module types within the 1769 family?

        Yes. The 1769-RTBN18/A is compatible with a wide range of 1769 Compact I/O modules (digital, analog, specialty) that use 18-point terminal interfaces, making it a versatile wiring accessory across multiple module classes.

      • Why is the 1769-RTBN18/A important for compact and distributed control topologies in factory automation?

        In compact or distributed control topologies, field wiring accessibility and maintainability are critical. The 1769-RTBN18/A simplifies connection points, enhances serviceability, and reduces installation time for CompactLogix I/O racks by providing a standardized terminal interface.
