1791D-OB16P

CompactBlock I/O for Devicenet
In Stock

Product Information:

CompactBlock I/O for Devicenet.

This module is a Sixteen (16) channel

sourcing output base module with

Eight (8) outputs per channel group.

Expand All
Collapse all

Technical specifications for 1791D-OB16P

  • Manufacturer:
    Allen-Bradley
  • Product Category:
    PLC System
  • Spare Part Number:
    1791DOB16P
  • Estimated shipping dimensions:
    15.2 cm x 5.1 cm x 4.4 cm
  • Weight:
    0.2 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
  • DeviceNet Power:
    11V - 25 V dc
  • No of outputs:
    Sixteen (16)
  • No. of output Groups:
    2 groups of 8
  • ON-state Voltage range:
    10 - 30V dc
  • ON-state Current:
    0.5A maximum
  • Module Current, all outputs:
    4.0A maximum
  • Output On-state Voltage Range:
    10-30V dc
  • Output On-state Current:
    0.5A max.
  • Stock:
    10

Manuals

Ask our team:

  • How is the output topology of the 1791D-OB16P configured and what electrical characteristics define it?
    The 1791D-OB16P provides sixteen sourcing output channels arranged in two groups of eight. Each channel supports an on-state voltage range of 10–30 V DC with a maximum on-state current of 0.5 A, and the entire module can deliver up to 4.0 A total load current.
  • What DeviceNet communication capabilities does the 1791D-OB16P support for distributed I/O systems?
    The 1791D-OB16P supports standard DeviceNet communication rates of 125 kbps, 250 kbps, and 500 kbps over both thick and flat media, enabling robust integration with ControlLogix, SLC, PLC-5, and other Rockwell Automation controllers that include DeviceNet scanners.
  • What integral status diagnostics are provided by the 1791D-OB16P for monitoring module and network health?
    The 1791D-OB16P incorporates multiple LED indicators to show Module/Network status (red/green), Logic status (green), and I/O activity (yellow), enabling rapid visual verification of communication integrity and output performance during commissioning and maintenance.
  • What overload and transient behavior specifications characterize the 1791D-OB16P outputs?
    Each output channel on the 1791D-OB16P withstands a surge current up to 1.0 A for 10 ms, repeatable every 2 seconds, facilitating reliable transient response for inductive loads and short-duration current spikes typically found in industrial actuation circuits.
  • What environmental and enclosure standards apply to the 1791D-OB16P for industrial facility deployment?
    The 1791D-OB16P is designed to meet IEC IP20 enclosure standards and operate within industrial ambient conditions, making it well-suited for protected control cabinets where discrete outputs must withstand mechanical and electrical stress.
  • What power supply considerations must be addressed when integrating the 1791D-OB16P into a DeviceNet segment?
    The 1791D-OB16P requires DeviceNet power within the range of 11 V to 25 V DC and typically draws up to 200 mA (with expansion modules attached), so ensuring adequate supply and network trunk power capacity is essential to avoid under-voltage conditions.
