Features:
- Proximity Probe Housing Assemblies
- Aluminum body with 304 stainless steel sleeve
- 21000 and 24701 Proximity Probe Housing Assemblies
The 21000 and 24701 Proximity Probe Housing Assemblies are available with Canadian Standards Association (CSA) approvals. They are rated explosion proof for hazardous areas. Bently Nevada offers a probe support and oil seal (part number 37948-01) for long sleeves that must go through an inner bearing housing.
To externally mount proximity probes, use one of these allmetal Proximity Probe Housing Assemblies: 21000 aluminum probe housing assembly; 24701 stainless steel probe housing assembly The 21000 and 24701 Proximity Probe Housing Assemblies consist of the following parts:A dome cover that screws into the body of the housing; Threaded ports for conduit connections; A probe sleeve of optional length; 0-rings; A reverse mount proximity probe; A thread seal; Optional conduit fittings; An optional standoff adapter.
The 21000-16-05-00-033-04-02 Bently Nevada Proximity Probe Housing Assemblies may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 21000-16-05-00-033-04-02 Proximity Probe Housing Assemblies Manuals(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 21000 Proximity Probe HousingAssemblies consist of the following parts:
A dome cover that screws into the body of the housing
- Threaded ports for conduit connections
- A probe sleeve of optional length
- O-rings
- A reverse mount proximity probe
- A thread seal
- Optional conduit fittings
- An optional standoff adapter
- External Mounting: Allows for external mounting of the proximity probe onto machinery (such as turbines or compressors), enabling clearance adjustment or probe replacement without disassembling the machine.
- API 670 Compliance: Fully compliant with the American Petroleum Institute (API) 670 standard requirements for externally mounted proximity probe housings.
- Hazardous Areas: The aluminum housing is explosion-proof and CSA Type 4 certified, suitable for use in hazardous industrial environments.
