      Bently Nevada 330930-045-04-00
      Bently Nevada 330930-045-04-00
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote

      330930-045-04-00

      3300 NSv Extension Cable
      In Stock
      Ships by Tuesday, June 23
      Fast Shipping Available

      Product Information:

      Part number 330930-045-04-00 refers to the Bently Nevada 3300 XL NSv short-distance extension cable, which features stainless steel armor, an FEP outer sheath, connector protectors, and a length of 4.5 meters.

      The NSv (Narrow Surface/Small Target) system is designed for space-constrained installation environments, such as centrifugal air compressors or process gas compressors, where standard 5mm and 8mm probes are subject to significant sidewall interference or target size limitations.

      Warranty Policy
      We provide 1 year warranty for all remaining parts.
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shiping Mode
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 330930-045-04-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        TSI System
      • Estimated shipping dimensions:
        15 x 1.2 x 10 cm
      • Weight:
        0.13 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Category Series:
        3300 NSv Series
      • Product Type:
        Extension Cable
      • Cable Length:
        4.5 meters (14.8 feet)
      • Connector and Cable:
        With stainless steel armor, with FEP jacket, with connector protector
      • Agency Approval:
        Not Required
      • Extension cable dc resistance:
        Center conductor: 0.220 Ω/m (0.067 Ω/ft);Shield: 0.066 Ω/m (0.020 Ω/ft)
      • Operating and Storage Temperature:
        -52°C to +177°C (-62°F to +351°F)
      • Relative Humidity:
        100% condensing, nonsubmersible when connectors are protected.Tested to IEC 68-2- 3 damp heat
      • Extension cable capacitance:
        69.9 pF/m (21.3 pF/ft) typical
      • Recommended Gap Setting:
        1.0 mm (40 mils)
      • Stock:
        100
      Ask for Quote

      Alternative Names

      330930 045 04 00 33O93O-O45-O4-OO 330930-045-04-05 330930-045-04-CN 330930-045-04-BR 330930-045-04-RU 330930-045-04-US 330930-045-01-00 330930-045-02-00 330930-045-06-00 330930-045-08-00 330930-045-11-00 330930-060-04-00 330930-040-04-00

      Information

      Overview Manuals Basic Info Ordering Information Integration & Hardware

      Features:

      • 3300 NSv Extension Cable
      • Radial vibration and radial position measurements
      • 3300 XL NSv Proximity Transducer System
      The 3300 NSv probe and extension cable are mechanically and electrically compatible and interchangeable with Bently Nevada’s previous 3300 RAM proximity probe and extension cable. The NSv probe has increased chemical resistance compared to the 3300 RAM probe, which allows its use in many process compressor applications. The side-view characteristics of the 3300 NSv probe are also superior to those of the 3000-series 190 probe when gapping the 3300 NSv probe at the same distance from the probe target.

      The 3300 NSv probe comes in varying probe case configurations, including armored and unarmored 1/4-28, 3⁄8-24, M8X1 and M10X1 probe threads. The reverse mount 3300 NSv probe comes standard with either 3⁄8-24 or M10X1 threads. All components of the transducer system have gold-plated brass ClickLoc connectors.

      The 330930-045-04-00 Bently Nevada 3300 NSv Extension Cable may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Bently Nevada 330930-045-04-00 3300 NSv Extension Cable Manuals(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      • Model: 330930-045-04-00
      • Warranty: One-year warranty
      • Condition: Brand new, original, in stock
      • Product Family: 3300 XL NSv Proximity Transducer System
      3300 NSv Extension Cable
      330930-Axxx-Bxx-Cxx

      A: Cable Length
      040: 4.0 meters (13.1 feet)
      045: 4.5 meters (14.8 feet)
      060: 6.0 meters (19.7 feet)
      065: 6.5 meters (21.3 feet)

      B: Connector and Cable
      00: Without stainless steel armor
      01: With stainless steel armor, with FEP jacket
      02: With stainless steel armor, without FEP jacket
      03: Without stainless steel armor, with connector protector
      04: With stainless steel armor, with FEP jacket, with connector protector
      05: With stainless steel armor, without FEP jacket, with connector protector
      06: FluidLoc cable without stainless steel armor
      07: FluidLoc cable with stainless steel armor, with FEP jacket
      08: FluidLoc cable with stainless steel armor, without FEP jacket
      09: FluidLoc without stainless steel armor, with connector protector
      10: FluidLoc cable with stainless steel armor, with FEP jacket, with connector protector
      11: FluidLoc cable with stainless steel armor, without FEP jacket, with connector protector

      C: Agency Approval
      00: Not Required
      05: Multiple Approvals
      Loop Matching: To maintain a system calibration scale factor of 7.87 V/mm (200 mV/mil), this 4.5-meter cable must be fully matched to the 0.5-meter NSv probe. Together, they meet the 5.0-meter total electrical loop length requirement for the matched 3300 XL NSv proximity sensor.
      Physical Protection: The 04 armor option provides robust stress protection for exposed wiring between the machine housing and the junction box. An integrated connector protector seals the gold-plated ClickLoc connection points against oil, water, and process moisture.

      Manuals

      Technical notes

      The Bently Nevada 330930-045-04-00 is an industrial-grade eddy current non-contact displacement sensor extension cable, belonging to the 3300 XL NSv series. It is designed for vibration and displacement monitoring systems in centrifugal air compressors, refrigeration compressors, and other rotating machinery with limited installation space or small shaft diameters. This 4.5-meter cable features stainless steel armor, an FEP fluoropolymer outer sheath, and connector protection layers, effectively protecting the internal 75Ω coaxial transmission cable from mechanical damage and chemical corrosion, making it suitable for harsh industrial environments ranging from -51°C to +177°C.

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • Why is the 330930-045-04-00 considered a key component in high-precision shaft vibration and displacement monitoring architectures?
        The 330930-045-04-00 is an integral part of the sensor system, maintaining calibration accuracy and ensuring measurement consistency for shaft position, vibration, and rotor dynamics monitoring applications.
      • How does the 330930-045-04-00 help maintain the linearity of calibration proximity probe mounting systems?
        The 330930-045-04-00 employs a controllable impedance and capacitance design to ensure the entire monitoring system maintains its specified linear response and measurement accuracy.
      • What advantages does the 045 (4.5 m) configuration of the 330930-045-04-00 offer for complex mechanical installations?
        By extending the distance between the probe and the signal conditioning electronics, the 330930-045-04-00 allows for flexible installation of the monitoring equipment while meeting system calibration requirements.
      • How does 330930-045-04-00 ensure electromagnetic compatibility in industrial environments with high electrical requirements?
        330930-045-04-00 employs industrial-grade shielding technology designed to reduce electromagnetic interference susceptibility and maintain signal quality.
      • Which industrial sectors most commonly deploy 330930-045-04-00 in critical machinery monitoring applications?
        330930-045-04-00 is commonly used in power generation, oil and gas processing, petrochemical facilities, LNG receiving terminals, refineries, and heavy industrial manufacturing plants.
