High-performance control processor module designed specifically for the Mark VIe distributed control system platform. Its primary functions are executing control logic, sequential management, and real-time data processing, making it suitable for industrial automation and power generation applications. As the central processing unit in the control architecture, the module coordinates communication between I/O modules, field devices, and monitoring systems to ensure stable and deterministic system operation.
It can handle critical tasks such as signal processing, alarm management, system diagnostics, and fault handling, while maintaining synchronized operation among distributed controllers. Its industrial-grade design allows it to be deployed in demanding environments such as turbines, power plants, and process control facilities where real-time performance and system integrity requirements are extremely high.
The IS200TRLYH1BGF GENERAL ELECTRIC Termination Relay Board may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
GENERAL ELECTRIC IS200TRLYH1BGF Termination Relay Board INFO (manual), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
This module receives analog and/or digital input signals from connected sensors or subsystems, performs signal isolation, filtering, and level conversion via onboard circuitry, and then transmits the processed data to the central controller via a high-speed backplane or internal communication bus. Simultaneously, it parses control commands from the main processor and distributes corresponding output signals to relevant field devices or subordinate modules. All of this is achieved through coordinated data exchange, electrical isolation, and embedded firmware logic.
1. Dimensions: This is a large rectangular PCB, approximately 17.8 cm wide x 33.02 cm high.
2. Mounting: This board is typically mounted in a Mark VI rack or cabinet using standard fasteners, or on a metal base.
3. Operating Environment: Rated operating temperature range is -30°C to +65°C.
4. Terminals: Two long black terminals on the left edge provide 48 screw terminals (numbered 1-48). These terminals can connect wires up to 12 AWG.
5. Output Channels: Equipped with 12 plug-in magnetic relays.
6. Relays 1-6: Configurable as dry contacts (Type C contacts) or to drive external solenoid valves via jumpers.
7. Relay Ratings: The relays are rated for 3.0 A current, with a response time typically within 10 milliseconds.
8. Field Power Supply: Supports multiple solenoid valve drive power supply options, including 125V DC, 115/230V AC, or optional 24V DC. Each power supply is protected by an independent fuse and can be selected via jumper.
