Features:
- Equips a visible 658 nm red laser (Class 1, eye-safe under normal operation)
- Runs on a wide DC range of 12 V to 30 V
- Configurable cycle speeds with a minimum response time down to 2.5 ms
This sensor offers exceptional measurement flexibility, supporting an ultra-long measurement range of 200 mm to 35,000 mm (when paired with the "Diamond-grade" reflective strip) and boasting an outstanding resolution of up to 100 µm.
Its multi-function output terminal Q2 seamlessly switches between 4 mA to 20 mA current output, 0 V to 10 V voltage output, or digital switch output, enabling seamless integration with a wide range of PLCs and control systems.
The DL35-B15552 SICK Mid-Range Laser Distance Sensor may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
SICK DL35-B15552 Mid-Range Laser Distance Sensor manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
This sensor offers exceptional connectivity and scalability, designed to integrate with standard industrial field infrastructure:
Analog Communication: Fully programmable, reversible dual outputs providing 4 mA to 20 mA current loops or 0 V to 10 V voltage signals.
Digital Output: Equipped with 1 to 2 adaptive push-pull (PNP/NPN) switch outputs to prevent short circuits.
Intelligent Networking: Built-in IO-Link interface. This allows for complete configuration control, remote teaching routing, trace diagnostics, and quick factory reset via software.
Enclosure Protection Rating: Features a robust and compact ABS plastic enclosure with IP65 and IP67 protection ratings, effectively preventing dust and moisture ingress.
Electrical Connections: Employs standard industrial-grade 5-pin M12 male connectors.
Heat Resistance: Operates reliably in harsh climatic conditions ranging from -30°C to +55°C.
