      Allen-Bradley 1762-L40BWA
      Allen-Bradley 1762-L40BWA
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Get a Quote

      1762-L40BWA

      Allen-Bradley MicroLogix 1200 40-point programmable controller
      In Stock
      Ships by Wednesday, August 19
      Fast Shipping Available

      Product Information:

      1762-L40BWA is an Allen-Bradley MicroLogix 1200 programmable controller manufactured by Rockwell Automation. It combines a 100…240 V AC power supply, 24 embedded 24 V DC inputs (20 standard and 4 fast inputs), 16 relay outputs, 6 KB memory, and an RS-232C interface in one 40-point controller.

      The primary serial channel supports DF1, DH-485, Modbus RTU, and ASCII. The controller can use up to six 1762 expansion I/O modules, subject to the system power-loading calculation. Typical uses are discrete machine and process-control applications that require local sensor inputs, relay outputs, and serial communications.

      Lifecycle: Rockwell Automation lists this catalog number as discontinued effective August 25, 2021. The replacement category is Engineering Replacement; the official product page does not name a direct drop-in catalog number. Migration therefore requires an engineering review of supply voltage, I/O type and count, relay loading, serial protocols, program conversion, expansion modules, wiring, dimensions, and certifications.

      Warranty Policy
      We provide 1-year warranty for all remaining parts.
      The warranty period is 1-year warranty from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      Return Notice
      The warranty period is 1-year warranty from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
      In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
      Shipping Methods
      Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
      Parts Availability
      Moore Automated offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
      Expand All
      Collapse all

      Technical specifications for 1762-L40BWA

      • Manufacturer:
        Allen-Bradley
      • Product Category:
        PLC Systems
      • Spare Part Number:
        1762L40BWA
      • Estimated shipping dimensions:
        160 × 90 × 87 mm (W × H × D); 6.30 × 3.54 × 3.42 in.
      • Weight:
        2.4 lbs (1.1 kg)
      • Country of origin:
        Singapore
      • Place of shipment:
        Xiamen, Fujian, China
      • Product family:
        MicroLogix 1200
      • Product type:
        40-point programmable controller
      • Power supply:
        100…240 V AC (-15%, +10%), 47…63 Hz
      • Embedded inputs:
        24 × 24 V DC (20 standard and 4 fast inputs)
      • Embedded outputs:
        16 relay outputs
      • Communication protocols:
        DF1, DH-485, Modbus RTU, ASCII
      • Communication interface:
        RS-232C port
      • Memory:
        6 KB
      • Dimensions (W × H × D):
        160 × 90 × 87 mm (6.30 × 3.54 × 3.42 in.)
      • Shipping weight:
        1.1 kg (2.4 lb)
      • Operating temperature:
        0…55 °C (32…131 °F) ambient
      • Storage temperature:
        -40…+85 °C (-40…+185 °F) ambient
      • Operating humidity:
        5…95% RH, non-condensing
      • Power supply usage:
        82 VA
      • Heat dissipation:
        22.0 W
      • Sensor power output:
        400 mA at 24 V DC
      • Output circuit type:
        Relay
      • Minimum relay load current:
        10 mA
      • Terminal screw torque:
        0.791 N·m (7 lb·in)
      • Series:
        MicroLogix 1200
      • Stock:
        30
      Ask for Quote

      Revisions

      Revision Part #

      Also known as

      1762-L40BWA/A
      1762-L40BWA Ser A, Series A, Rev A
      Get Parts Quote
      1762-L40BWA/B
      1762-L40BWA Ser B, Series B, Rev B
      Get Parts Quote
      1762-L40BWA/C
      1762-L40BWA Ser C, Series C, Rev C
      Get Parts Quote

      Alternative Names

      1762L40BWA 1762 L40BWA 1762-L40BWAR 1762-L40AWA 1762-L40AWAR 1762-L40BXB 1762-L40BXBR 1762 expansion I/O modules

      Information

      Overview Manuals Principle Core Industrial Applications Hazardous Area Certifications

      Features:

      • MicroLogix 1200 40-point controller module
      • Features 24 inputs, is compatible with 24V DC input voltage
      • Supports both sinking and sourcing wiring configurations
      The input channels are designed to connect 24VDC input devices, supporting both sinking and sourcing wiring. The outputs are contact-type outputs, rated at 25-125VDC or 120-240VAC, with a mechanical life of 20,000,000 cycles and a minimum load current of 10A.

      Since the 1762-L40BWA is electronic equipment, it needs to be installed in a well-protected enclosure. The enclosure temperature must be maintained between +0°C and +55°C. Depending on the installation location, it is recommended to install suitable temperature control equipment within the enclosure, such as a heater, fan, or a combination of both

      The 1762-L40BWA Allen Bradley 40-point controller module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).

      Manufacturer documentation

      Rockwell Automation publications:
      • 1762-UM001I-EN-P, MicroLogix 1200 Programmable Controllers User Manual, May 2024
      • 1762-IN006, MicroLogix 1200 installation instructions
      • 1761-SG001, MicroLogix programmable controllers selection guide
      No external PDF has been copied, rebranded or uploaded to this page.
      This controller integrates an 8-pin Mini DIN RS232 communication port, supporting DH-485, DF1 full-duplex and half-duplex, Modbus master and slave protocols, and ASCII protocol. DF1, ASCII, and Modbus operate internally in point-to-point mode. This serial port can be multiplexed using converters to enable communication with multiple devices. These converters can be RS223 to Ethernet converters or RS232 to RS485 converters.
      This controller is widely used in industries requiring cost-effective and powerful machine-level automation:
      Manufacturing and Machine Control: Suitable for assembly lines, packaging machinery (filling, capping, labeling), and CNC machine tools.
      Material Handling: Controls conveyor systems and sorting equipment in warehouses or production facilities.
      Building Automation: Manages HVAC systems to optimize energy use and maintain environmental conditions.
      Utilities and Process Control: Used for pump and valve control in water and wastewater treatment, as well as power distribution load balancing.

      Hazardous Area Certifications

      Rockwell publication 1762-UM001I-EN-P includes Class I, Division 2 installation requirements for MicroLogix 1200 controllers, including use of the specified communication cables and explosion-hazard precautions. Certification is determined by the marking on the exact controller or its packaging; verify that marking and the applicable certificate before installation in a hazardous location.

      Technical notes

      Rockwell Automation classifies 1762-L40BWA as an Engineering Replacement rather than a published drop-in substitution. Before migration, verify 100…240 V AC supply compatibility, 24 V DC input characteristics, 16 relay-output loading and grouping, DF1/DH-485/Modbus RTU/ASCII communications, RSLogix 500 program conversion, 1762 expansion-I/O loading, wiring, mounting dimensions, and required certifications. Do not assume that another 1762-L40 controller suffix is interchangeable: AWA, BWA, BXB, and R versions have different input, output, power, or communication configurations.

      • Product Lifecycle Stage

        Obsolete/Discontinued by OEM; Active/Available from OEM

        Moore Automated provides high-quality Allen-Bradley replacement modules and spare parts for both traditional and modern industrial automation systems. Our reliable solutions help minimize unplanned downtime, extend equipment life, and ensure your production processes operate efficiently.

      Ask our team:

      Related Products

      Browsing history

      FAQ

      View All Faqs
      • What is the Allen-Bradley 1762-L40BWA?
        It is a MicroLogix 1200 40-point programmable controller with an AC power supply, 24 DC inputs, and 16 relay outputs.
      • How many inputs and outputs does the 1762-L40BWA have?
        It has 24 embedded 24 V DC inputs—20 standard and 4 fast inputs—and 16 embedded relay outputs.
      • What power supply does the 1762-L40BWA require?
        The controller accepts 100…240 V AC, -15% to +10%, at 47…63 Hz.
      • Does the 1762-L40BWA have built-in Ethernet?
        Rockwell lists an RS-232C interface and DF1, DH-485, Modbus RTU, and ASCII communications for this model; the official product specification does not list an embedded Ethernet port.
      • How much memory does the 1762-L40BWA have?
        Rockwell lists 6 KB of memory for catalog number 1762-L40BWA.
      • Is the 1762-L40BWA discontinued?
        Yes. Rockwell Automation lists it as discontinued effective August 25, 2021.
      • Is there a direct drop-in replacement for the 1762-L40BWA?
        Rockwell assigns the replacement category “Engineering Replacement” and does not name a direct drop-in catalog number on the product page. A migration review is required before substitution.
      • Can the 1762-L40BWA use expansion I/O?
        Yes. The MicroLogix 1200 manual permits up to six 1762 expansion I/O modules, subject to the system power-loading calculation.
