Features:
- Distributed analog input Modicon Momentum - 16 Input
- Configurable to read standard industrial current ranges from 4 to 20 mA, as well as voltage configurations of ±5 V and ±10 V
- Provides data processing at a full 16-bit signed resolution with an absolute accuracy error rating of ±0.15% of full scale at 25°C
This product is part of the Modicon Momentum range, an offer of controllers for IP20 monoblock I/Os. This analog input base offers 16 inputs with a full 16bit signed resolution. It offers analog input ranges from 4mA to 20mA, ±10V, ±5V. There is an isolation between channels and ground at 1780V AC, supply and ground at 500V. It is furnished with 2 removable terminal blocks for electrical connection. It features 16 LEDs for channel status signaling. It is suitable for infrastructures and energy, material handling and simple machine control applications.
This product is certified by CE, CSA, FM Class 1 Division 2 and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snaps together in various combinations to form versatile control systems or subsystems.
The 170AAI14000 Schneider Electric Analog Input Base Module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Schneider Electric 170AAI14000 Analog Input Base Module manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
From a lifecycle perspective, Schneider Electric plans to officially cease production (and sales) of this product on December 1, 2027, and has committed to continuing to provide standard after-sales maintenance and spare parts services until December 31, 2035. Currently, this product remains a critical MRO (Maintenance, Repair, and Operation) spare part for routine replacement and maintenance of many mature and still-operating aging production lines in industries such as water treatment, metallurgy, and digital transformation of factories.
1.Distributed Network Architecture: Designed for easy integration with various Momentum network adapters (Interbus, Modbus Plus, ControlNet, Profibus, or Ethernet), enabling easy distributed deployment of I/O nodes.
2.Process Infrastructure: Widely used in water treatment and wastewater treatment plant operations, energy management control, and material handling systems.
3.Compact Skid-Mounted Enclosure: Ideal for modular assembly units or remote pumping skids requiring a compact IP20 panel size and high analog channel density.
