Features:
- SIPLUS ET 200M active bus module
- Based on 6ES7195-7HD10-0XA0 with conformal coating, -40…+70 °C, start up -25 °C
- Active module bus base designed for holding 2 x IM 153-2 high-feature interface modules in a redundant configuration
The primary function of this module is to support redundant integrated installation of dual-interface modules (IM 153-2) in Siemens distributed I/O systems. It allows two IM 153-2 interface modules to be inserted into the same base simultaneously, creating a highly available (fault-tolerant) PROFIBUS-DP bus communication link.
Its key advantage lies in its support for hot-swapping (plug and play). This means that during PLC system operation, operators can directly replace damaged interface modules without power interruption, ensuring "zero-interruption" operation of industrial field communication.
The 6AG1195-7HD10-2XA0 Siemens Active bus module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6AG1195-7HD10-2XA0 Active bus module manual(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Altitude during operation relating to sea level
1.Installation altitude above sea level, max.: 5 000 m
2.Ambient air temperature-barometric pressure-altitude: Tmin ... Tmax at 1 140 hPa ... 795 hPa (-1 000 m ... +2 000 m) // Tmin ... (Tmax
- 10 K) at 795 hPa ... 658 hPa (+2 000 m ... +3 500 m) // Tmin ... (Tmax -20 K)
at 658 hPa ... 540 hPa (+3 500 m ... +5 000 m)
The module's proactive architecture determines its role in high-availability systems:
Smooth communication failover: The module is equipped with a primary communication interface and a backup communication interface. If the primary IM 153-2 module fails or goes offline, the backplane immediately switches the fieldbus link (PROFIBUS/PROFINET) to the backup module within milliseconds, ensuring uninterrupted process data transmission.
Power-off maintenance (hot-swappable): Allows for the complete removal and insertion of communication nodes during system operation without interrupting power to adjacent I/O modules on the rack or interfering with the fieldbus ring topology.
Deployment in harsh environments: Because the module is manufactured to Siemens SIPLUS extreme ruggedization standards, it outperforms standard SIMATIC hardware when the backplane must withstand extremely low temperatures, high altitudes, or highly corrosive environments.
