- Power supply module
- SITOP Modular/1AC/24VDC/20A
- SITOP modular 20 A stabilized power supply input: 120/230 V AC output: 24 V DC/20 A
The industrial power module designed to provide stable DC power for automation and control systems. It is typically used to provide a reliable 24V DC power supply to PLCs, sensors, communication modules, and other control devices within industrial cabinets. This module is designed for high efficiency and reliability, ensuring a stable power supply to connected devices even under fluctuating loads.
In practical applications, the 6EP1336-3BA00 enhances system reliability by providing overload protection, short-circuit protection, and overheat monitoring. Its compact design makes it easy to mount on DIN rails in control panels, making it suitable for manufacturing systems, process automation environments, and machine control systems. This power supply also supports stable operation in harsh industrial environments where voltage stability and electrical protection are critical.
The 6EP1336-3BA00 Siemens Power supply module may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6EP1336-3BA00 Power supply module datasheet(Datasheets), Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The input AC voltage is first rectified into DC, then converted into a high-frequency signal by a switching transistor. This signal is then regulated and isolated by a transformer, followed by rectification and filtering to finally produce a stable 24V DC output. Through the feedback control circuit, the module continuously monitors the output voltage and adjusts the switching operation to maintain a stable and efficient power output.
Siemens has officially begun phasing out this specific model.
Phase-out Date: Effective October 1, 2014.
Replacement Model: The recommended replacement model is the SITOP PSU8200 (6EP1336-3BA10), which is more efficient (93%) and has a more compact design.
