      VM600 MPC4 200-510-070-112

      VM600 MPC4 machinery protection card

      Product Information

      Product Describe

      VM600 MPC4 machinery protection card

      Programmable broad-band and narrow-band filters

      Programmable Alert, Danger and OK set points

      Adaptive Alert and Danger levels

      Technical specifications for VM600 MPC4 200-510-070-112

      • Manufacturer:
        Vibro-Meter
      • Product Category:
        General Automation
      • Estimated shipping dimensions:
        20.5 x 8 x 13.6 cm
      • Weight:
        0.56 kg
      • Tariff Code:
        8537101190
      • Country of origin:
        USA
      • Place of shipment:
        Xiamen, Fujian, China
      • Number of inputs:
        4 per MPC4 card
      • DC range:
        0 to +20 V or 0 to −20 V
      • AC range:
        ±10 V max.
      • Common mode voltage range:
        −50 to +50 V
      • Input impedance:
        200 kΩ
      • Current measuring resistor:
        324.5 Ω
      • Operating Temperature:
        −25 to 65°C (−13 to 149°F)
      • Storage Temperature:
        −40 to 85°C (−40 to 185°F)
      • Stock:
        20

      • New and original with factory sealed packing

        Brand new and 100% original unit, supplied in factory-sealed packaging, ensuring untouched condition and full manufacturer integrity.

      • New in opened package

        These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged.

      • New surplus

        New surplus item in unused condition, originally manufactured for distribution but not deployed in service.

      • Refurbished

        This product has been repaired by an authorized service center, and worn or aged parts have been replaced with qualified genuine parts. Warranty terms are subject to refurbishment certification and service policies.

      More Information

      Overview Manuals Applications information Main advantages and features

      Features:

      • VM600 MPC4 machinery protection card
      • Continuously online machinery protection card
      • Programmable broad-band and narrow-band filters
      The MPC4 Mechanical Protection Card is a core component of the Meggitt Vibro-Meter® product line, particularly the VM600 Series Mechanical Protection System (MPS). This powerful card can simultaneously measure and monitor up to four dynamic signal inputs and two velocity inputs.

      The dynamic signal inputs are fully programmable, accepting signals representing acceleration, velocity, and displacement (proximity). Onboard multi-channel processing measures a variety of physical parameters, including relative and absolute vibration, maximum vibration intensity (Smax), eccentricity, thrust position, absolute and differential housing expansion, displacement, and dynamic pressure.

      The VM600 MPC4 200-510-070-112 Vibro-Meter Machinery protection card may still be available for purchase and support from Moore Automated Company beyond End-Of-Life (EOL) by the manufacturer (OEM).
      Vibro-Meter VM600 MPC4 200-510-070-112 Machinery protection card manual(Datasheets), Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      Machinery protection and/or basic condition monitoring
      When used in conjunction with the IOC4T input/output card, the MPC4 is ideal for machine monitoring and protection in a variety of industrial applications. For general information on the use of the MPC4/IOC4T card pair, please refer to the VM600 Machine Protection System (MPS) Hardware Manual and the VM600 MPSx Software Manual. For information on the use of the MPC4/IOC4T card pair in functional safety environments, please refer to the VM600 Functional Safety Manual.
      • Front-panel LEDs indicate status and alarms
      • Integrated power supplies for sensors and signal conditioners such as IEPE
      • accelerometers and proximity measurement systems
      • Live insertion and removal of cards (hot-swappable)
      • Available in “standard”, “separate circuits” and “safety” (SIL) versions
      By purchasing this item, you agree to the Terms & Conditions
      Moore Automated is NOT an authorized distributor of Vibro-Meter
      right background
      1-year warranty

      All our products come with a 1-year warranty for your peace of mind.

      Service means taking a customer problem and making it your own challenge. Years of experience and listening skills enable us to think and act quickly and accordingly. You have a problem? – We have the solution!
      Moore Automated is not an authorized distributor, reseller or representative of the products featured on this website.
      All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
      Learn More Policy
      Manuals
      • Order Online:
        We have been working hard to update our inventory.

        If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show “Ask”. Please create an online quote or contact us by phone, fax or email to check availability.
      • Order by:
        You can also contact us by phone, fax or email to order. We are here to help you!
      • E-mail:
        We need the following information to process your order quickly and accurately: Your complete ship and receipt information
      • Delivery:
        How do you want to ship? Shipping information
      • Payment:
        How will you pay? Payment procedure
      Learn More Policy
      Quantity*
      Mobile*
      Company
      E-mail*
      Content*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote

      Quick Search

      • Part or Model Number

        • Please try to be as accurate as possible with your search.
        • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
        • We can't find any results for “”.
          SEE MORE
            SEE PRODUCTS IN SEARCH PAGE ()

          • Filter by Manufacturer

          • Filter by Category

          Featured Manufacturers

          FAQ

          • What are the main functions of the VM600 MPC4 200-510-070-112 in the Vibro-Meter VM600 machine protection platform?
            The VM600 MPC4 200-510-070-112 is a high-performance machine protection and condition monitoring processor card designed to acquire, process, and evaluate dynamic vibration signals for critical rotating machinery protection systems.
          • How does the VM600 MPC4 200-510-070-112 perform real-time vibration signal conditioning and protection logic?
            The VM600 MPC4 200-510-070-112 performs multi-channel signal acquisition and integrates filtering, scaling, and digital processing algorithms to derive real-time vibration parameters such as displacement, velocity, and acceleration.
          • Why is the VM600 MPC4 200-510-070-112 crucial for mission-critical turbomachinery protection architectures?
            The VM600 MPC4 200-510-070-112 provides deterministic protection logic execution, enabling rapid detection of abnormal vibration conditions such as imbalance, misalignment, rotor friction, and bearing degradation.
          • What diagnostic and fault assessment functions are built into the VM600 MPC4 200-510-070-112?
            The VM600 MPC4 200-510-070-112 supports continuous self-diagnostics, channel health monitoring, and alarm threshold assessment to ensure early detection of equipment anomalies and system performance degradation.
          • How is the VM600 MPC4 200-510-070-112 integrated into the VM600 rack-mount architecture?
            The VM600 MPC4 200-510-070-112 operates as a modular card within the VM600 chassis, communicating with other processing and communication modules via a backplane interface to achieve centralized device protection control.
